Zenoah BCZ2600SW User Manual
Page 53
53
Fig.1 DRIVE UNIT BCZ2600SW (S/N 60100101 and up)
101
9” 22-tooth
SST229
1
102
9” 24-tooth
SST249
1
103
8” 8-tooth
SGB088
1
104
9” 8-tooth
SGB089
1
105
8” 4-tooth
SGB048
1
106
9” 4-tooth
SGB049
1
107
COVER
3540-13283
1
108
HOLDER
6019-13250
1
109
GUARD
T3246-24110
1
Key#
Description
Part Number
Q'ty
1
PIPE-COMP, 1500xø24xT1.7
848-J8S-5820
1
2
• SEAL
T3400-12130
1
3
SHAFT, 1536xø7, spline 7T
3520-12213
1
4
GEARCASE ASSY
848-JP3-6100
1
5
• GEARCASE
6440-13122
1
6
• BEARING
T3300-13521
1
7
• BEARING
T3403-13510
1
8
• RING
04065-02612
1
9
• SEAL
3565-13130
1
10
• SHAFT
T3002-13210
1
11
• GEAR
6440-13220
1
12
• NUT, M10
T3002-13260
1
13
• PINION
T3002-13310
1
14
• BEARING
T3300-13531
1
15
• BEARING
T3403-13530
1
16
• RING
T3300-13330
1
17
• RING
04065-02412
1
18
• BOLT
T4950-51200
1
19
• BOLT
T4950-52500
1
20
• HOLDER (A)
6440-13242
1
21
• FITTING, grease
3199-13350
1
22
• WASHER
01641-20608
1
23
HANGER COMP.
T3300-17202
1
24
• SCREW
848-805-2000
1
25
LABEL NAME & CAUTION
848-JP4-90R0
1
31
HANDLE-L COMP.
T3040-14200
1
32
HANDLE-R COMP.
T3002-95400
1
33
LEVER-ASSY
6234-14601
1
34
• COVER COMP.
6234-14601-02
1
35
• SHAFT
6110-14410-06
1
36
• BUTTON
6110-14410-09
1
37
• SPRING
6110-14410-08
1
38
CORD(A) BLACK
T3002-95710
1
39
CORD(B) RED
T3002-95720
1
40
CABLE COMP.
T3040-83100
1
41
TUBE
5512-73220
1
42
CLAMP
3260-14251
1
43
SCREW
0260-00516
1
44
BRACKET ASSY
848-JC1-3230
1
45
• BRACKET
3583-14111
1
46
• CAP-L
3583-14121
1
47
• CAP-U
3257-14192
1
48
• BOLT
4820-13180
2
49
• BOLT
T4950-52500
4
50
PROTECTOR
T3310-17111
1
51
BAND
3540-93120
1
53
GUARD COMP.
T3245-24100
1
54
• BLADE
T3002-24121
1
Key#
Description
Part Number
Q'ty
55
• SCREW
T4960-51431
1
56
• NUT
3320-15310
1
57
BRACKET
848-JC0-66C1
1
58
BOLT
T4950-63000
2
61
STRAP ASSY
848-B50-3610
1
62
TOOL-SET
848-8U0-0120
1
65
• SOCKET
848-8U1-0040
1
66
• BAR
3540-91110
1
67
GOGGLE
848-A56-92C0
1
68
TAP HEAD COMP.
PT104 Plus
1
69
• CASE
T3189-15112
1
70
• EYELET
T3189-15191
2
71
• COVER
T3189-15132
1
72
• CORD HOLDER
T3189-15142
1
73
• SPRING
T3189-15160
1
74
• CORD
T3189-15180
1
OPTIONAL BLADE
