P-660H-Tx v2 Support Notes

server sets

ip nat server save

Save the NAT server set buffer into flash

ip nat server clear [set#]

Clear the server set [set#], must use “save” command

to let it save into flash

ip nat server edit [rule#] active

Activate the rule [rule#], rule number is 1 to 24, the

number 25-36 is for UPNP application

ip nat server edit [rule#] svrport

port>

Configure the port range from to

port>

ip nat server edit [rule#] remotehost

Configure the IP address range of remote host (Leave

it to be default value if you don’t need this command)

ip nat server edit [rule#] leasetime

Configure the lease time (Leave it to be default value if

you don’t want this command)

ip nat server edit [rule#] rulename

Configure the name of the rule (Leave it to be default

value if you don’t want this command)

ip nat server edit [rule#] forwardip

address>

Configure the LAN IP address to be forwarded

ip nat server edit [rule#] protocol

Configure the protocol to be used TCP , UDP or ALL

(it must be capital)

NAT Server Sets

The NAT Server Set is a list of LAN side servers mapped to external ports
(similar to the old SUA menu of before). If you wish, you can make inside
servers for different services, e.g., Web or FTP, visible to the outside users,
even though NAT makes your network appears as a single machine to the
outside world. A server is identified by the port number, e.g., Web service is on
port 80 and FTP on port 21.

As an example (see the following figure), if you have a Web server at
192.168.1.36 and a FTP server at 192.168.1.33, then you need to specify for
port 80 (Web) the server at IP address 192.168.1.36 and for port 21 (FTP)
another at IP address 192.168.1.33.
