36 Freedom SW 3000 Owner’s Guide
Configuration
If you choose Yes, the equalization process is cancelled and you are
returned to the Freedom SW 3000 home menu.
If you choose No, the equalization home screen as shown in Figure 23
appears.
Table 5 Equalization Home Screen Content
Equalization Home
Screen content
Explanation of items displayed
Precharging • “Yes”—precharging occurs if batteries are not
fully charged before equalization. Batteries
must be fully charged before equalization.
• “Done”—indicates the precharge is complete
or if it was not required.
Time Remaining Indicates the time left for equalization.
Equalization runs for 60 minutes and is counted
down in 1 minute increments until the Time
Remaining displays 0 min. (During a precharge,
the Time Remaining displays
“n/a”— not applicable.)
Battery Voltage Displays a range of 13.0 to 18.0V with a resolution
of 0.1V.
Menu Pressing Menu returns you to Select Device
screen.
Cancel Pressing Cancel will display a confirmation screen,
as shown in Figure 24, asking you to confirm that
you want to cancel equalization.
Figure 24 Equalization Cancellation Warning
Yes No
want
Equalization?
