Connect your CD player, MD player or tape deck via analog and/or digital connections.
Do not connect this unit or other components to the AC power supply until all connections between
components are complete.
To make a digital connection to a component other than the default component assigned to each DIGITAL INPUT or DIGITAL
OUTPUT jack, select the corresponding setting for “OPTICAL OUT”, “OPTICAL IN”, or “COAXIAL IN” in “I/O ASSIGNMENT”
(see page 82).
Connecting a CD player, an MD player or a tape deck
Note
CAUTION
AUDIO DIGITAL INPUT
MD/CD-R MD/CD-R
OUT
(REC)
IN
(PLAY)
MD/
CD-R CD
DIGITAL
OUTPUT
OPTICAL OPTICAL
L R
L R L R
O
O
CD player
MD recorder or
tape deck
(U.S.A. model)
Audio out
Audio out Audio in
O
p
tic
al
au
di
o ou
t
O
p
tic
al
au
di
o in
