Description of the hob – Zanussi ZGF 782 User Manual
Page 5
5
1. Hob Top
2. Auxiliary Burner
3. Semi-rapid Burners
4. Ultra-rapid Double-crown Burner
5. Rapid Burner
6. Ignition pushbutton
7. Control knob for front left burner (auxiliary)
8. Control knob for back left burner (semi-rapid)
9. Control knob for central burner (ultra-rapid)
10. Control knob for back right burner (semi-rapid)
11. Control knob for front right burner (rapid)
1
3
2
4
5
6 7
8 9
3
10 11
Description of the Hob
INSTALLATION
Any gas installation must be carried out by a
registered CORGI installer, and in
accordance with existing rules and
regulations.
The relevant instructions are to be found in
the second section of this manual.
Please, ensure that, once the hob is installed,
it is easily accessible for the engineer in the
event of a breakdown.
WHEN THE HOB IS FIRST INSTALLED
Once the hob has been installed, it is
important to remove any protective
materials, which were put on in the factory.
