System architecture – ZyXEL Communications IES-1000 User Manual
Page 5
IES-6000M
ELC1220G-55
MSC1224G
MSC1024G
Control Card
Control Card
Ethernet Line Card
Ethernet Line Card
ALC1248G-53
VLC1324G-51
VLC1348G-51
VLC1324G-53
VLC1424G-56
VOP1248G-61
ALC1248G-51
SLC1248G-22
ALC1272G-51
ADSL Line Card
ADSL Line Card
G.SHDSL Line Card
G.SHDSL Line Card
VDSL2 Line Card
VDSL2 Line Card
VoIP Line Card
VoIP Line Card
IMA1408G-81
E1 IMA Card
E1 IMA Card
System Architecture
