Page 15

63
This appliance complies with the
following E.E.C. Directives:
-
73/23 - 90/683 (Low Voltage Directive);
-
89/336 (Electromagnetical Compatibility
Directive);
-
93/68 (General Directives)
and subsequent modifications.
Height
59,4 cm
Width
56,0 cm
Depth
55,0 cm
Height
32,5 cm
Width
42,0 cm
Depth
39,0 cm
Volume
53 l
RECESS
DIMENSIONS
OVEN CAVITY
DIMENSIONS
TECHNICAL DATA
MANUFACTURER:
ELECTROLUX ZANUSSI
ELETTRODOMESTICI S.p.A.
Viale Bologna, 298
47100 FORLÌ (Italie)
Oven thermostat settings: from 50
°
C up to 250
°
C
Heating elements ratings
Bottom heating element
1000 W
Top heating element
800 W
Full Oven (Top+Bottom)(1000 + 800)
1800 W
Grill heating elements simple
1750 W
double
2550 W
Fan Oven heating element
2000 W
Oven lamp
25 W
Convection fan
30 W
Cooling fan
25 W
Maximum power rating (230V - 50Hz)
2600 W
Voltage tension (50 Hz)
230 V
FO 0414
TO THE ATTENTION OF THE INSTALLER
The following instructions are meant to a qualified
technician, in order to allow him carry out the
installation in compliance with the rules in force.
The building-in and the electrical connection fo the
appliance must be carried out by a qualified and
authorized technician only.
BUILDING IN
It is important that the dimensions and materials of the
surround or cabinet into which the oven will be built are
correct and will withstand a temperature increase.
A correct installation will have to ensure a proper
protection against contact with electric parts or merely
functionally isolated parts.
All the units meant to ensure protection have to be fitted
not to be taken away without using any tool.
We recommed not to install the appliance near
refrigerators or freezer, since the heat could affect the
performance of these appliances.
Oven dimensions (Fig. 10)
