DESCRIPTION OF THE APPLIANCE
4
OPERATION
Freezer controls
Before use
Remove all securing tapes. Wash inside the appliance
with lukewarm water and bicarbonate of soda
(5 ml to 0.5 litre of water). Do not use soap or deter-
gent as the smell may linger. Dry thoroughly.
➀
Freezer calendar
➁
Freezer control
➂
Compartment for frozen
food storage
➃
Compartment for freezing
fresh food
➄
Thermometer
➀
➁
➂
➂
➃
➃
1
2
3
4
5
6
A B C D E F G
➀
Thermostat
➁
Pushbutton ON/OFF
➂
Operation light
➃ Warning light
➄
Fast-freezing indicator light
➅
Pushbutton for fast-freezing and for stopping the audible signal (warning light on)
➆
Symbol for audible alarm (temperature warning and open door warning)
➀ ➁ ➂ ➃ ➄ ➅ ➆
° C
