Building the appliance in under a worktop – Zanussi ZU 9100 F User Manual
Page 16
16
Building the appliance in under a
worktop
The dimensions of the recessed installation area must
correspond with those indicated in the figure.
Remove covering and adjusting strips.
Push the appliance into place. The plug socket neces-
sary for connection of the appliance to the electricity
supply should be positioned, so that the plug is not
placed in the recess.
Adjust height.
DO013
600
550
min.
600
S.I.005
