Maintenance
4-10 975-0057-01-01
3. Disconnect the wires on the battery only.
4. After removing the old battery, position the new battery
close to the back of the XPower Powerpack .
Make sure the positive battery terminal is next to the red
positive (+) internal cable and the black negative terminal
is next to the black negative (–) internal cable.
5. Securely fasten the bolt and washer that holds the red
positive (+) cable to the positive (+) battery terminal and
the black negative (–) cable to the negative (–) battery
terminal.
6. Do not overtighten the bolt. Consult the battery
manufacturer for torque specifications.
Fasteners
