Page 5
1
4050-11110
HOUSING
1
2
4050-11150
CAP
1
3
4050-11210
JOINT
1
4
4050-11250
ABSORBER-F
1
5
4050-11260
ABSORBER-R
1
6
01252-30530
BOLT
4
7
01252-30630
BOLT
1
8
01252-30510
BOLT
1
9
T3113-11310
DRUM
1
10
06004-06202
BEARING
1
11
04065-03515
RING
1
12
04064-01510
RING
1
13
3544-11510
BOLT
4
14
T3113-12100
PIPE COMP
1
ø26x1500
15
3520-12213
SHAFT, spline ø7x7teeth
1
ø7x1536
16
6522-13000
GEARCASE ASSY
1
17
6522-13110
• GEARCASE
1
18
06000-06000
• BEARING
2
19
06000-06202
• BEARING
1
20
3130-13141
• SEAL
1
21
04065-03515
• RING, SNAP
1
22
01252-30510
• BOLT
1
23
3540-13212
• SHAFT
1
24
3540-13220
• GEAR,
1
25
3544-13280
• WASHER
1
26
01643-31032
• WASHER
1
27
3540-13290
• BOLT
1
M10(L)
28
6522-13310
• PINION
1
29
06001-06000
• BEARING
1
30
3180-13330
• RING
1
31
04065-02612
• RING
1
32
3540-13260
• BOLT
1
33
0224-40610
• BOLT
1
34
6251-13240
• HOLDER(A)
1
35
3540-13251
• HOLDER(B)
1
36
3530-14900
BRACKET ASSY
1
37
3540-14910
• BRACKET
1
38
3540-14920
• CAP-L
1
39
3540-14930
• CAP-U
1
40
3540-14140
• ABSORBER
2
41
3540-14150
• CLAMP
1
42
3540-14160
• CLAMP
1
43
01252-30525
• BOLT
6
44
01252-30530
• BOLT
4
45
3530-14171
• SPACER
2
46
6520-17100
HANGER ASSY
1
47
6520-17110
• HANGER
1
48
6520-17120
• CLAMP
1
49
6520-17130
• SPACER
1
50
0263-90525
• SCREW
1
51
T3113-12510
PLATE, name
1
52
T3113-12590
PLATE, number
1
53
6425-12552
PLATE, caution
1
54
6489-24000
GUARD ASSY
1
55
6489-24110
• GUARD
1
56
6489-24200
• PLATE COMP
1
57
6489-24210
• • PLATE
1
58
6489-24220
• • BLADE
1
59
0277-10412
• • SCREW
1
60
6489-24120
• PLATE
1
61
01252-30516
• BOLT
4
62
01601-20513
• WASHER
4
63
3540-13283
COVER
1
64
6251-15910
COVER
1
Key#
PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
65
6220-17202
HARNESS ASSY
1
66
4050-17110
PROTECTOR
1
67
3540-93120
BAND
1
68
6298-14343
SAW
1
69
T3111-14300
HANDLE-L COMP
1
70
T3113-14100
HANDLE-R COMP
1
71
T3111-14110
• HANDLE-R
1
72
K6010-000550
• GRIP&LEV, COMP
1
73
K2200-000040
• • LABEL
1
74
K2300-000050
• • GRIP (L)
1
75
B1181-040545
• • NUT
1
76
K2300-000080
• • SWITCH
1
77
K5100-000030
• • SPRING
1
78
K5100-000040
• • SPRING
1
79
K2300-000090
• • HOLDER
1
80
B1122-C2910H
• • SCREW, M3x10
2
Tapping
81
K5100-000020
• • SPRING
1
82
K2300-000070
• • LEVER
1
83
K5100-000010
• • SPRING
1
84
K2300-000060
• • LEVER
1
85
K1300-000060
• • PLUG
1
86
K5100-000050
• • SPRING
1
87
K2300-000040
• • GRIP (R)
1
88
B1111-A0530H
• • SCREW, M5x30
1
89
B1122-C4220H
• • SCREW, M4x20
5
Tapping
90
K5200-000070
• CORD
1
91
K5100-000130
• CABLE
1
92
K5200-000080
• TUBE
1
93
T3113-91000
TOOL KIT
1
94
1030-91340
• DRIVER
1
95
3144-91160
• SOCKET
1
96
09007-00425
• WRENCH
1
97
09007-00528
• WRENCH
1
98
3540-91110
• BAR
1
99
T3115-93110
MANUAL
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.2 CUTTER GROUP
BC3401DWM
