Fig.1 cutter group, Bc3401dlm – Zenoah BC3401DWM User Manual
Page 3
1
4050-11110
HOUSING
1
2
4050-11150
CAP
1
3
4050-11210
JOINT
1
4
4050-11250
ABSORBER-F
1
5
4050-11260
ABSORBER-R
1
6
01252-30530
BOLT
4
7
01252-30630
BOLT
1
8
01252-30510
BOLT
1
9
T3113-11310
DRUM
1
10
06004-06202
BEARING
1
11
04065-03515
RING
1
12
04064-01510
RING
1
13
3544-11510
BOLT
4
14
T3113-12100
PIPE COMP
1
ø26x1500
15
3520-12213
SHAFT, spline ø7x7teeth
1
ø7x1536
16
6522-13000
GEARCASE ASSY
1
17
6522-13110
• GEARCASE
1
18
06000-06000
• BEARING
2
19
06000-06202
• BEARING
1
20
3130-13141
• SEAL
1
21
04065-03515
• RING, SNAP
1
22
01252-30510
• BOLT
1
23
3540-13212
• SHAFT
1
24
3540-13220
• GEAR
1
25
3544-13280
• WASHER
1
26
01643-31032
• WASHER
1
27
3540-13290
• BOLT
1
M10(L)
28
6522-13310
• PINION
1
29
06001-06000
• BEARING
1
30
3180-13330
• RING
1
31
04065-02612
• RING
1
32
3540-13260
• BOLT
1
33
0224-40610
• BOLT
1
34
6251-13240
• HOLDER(A)
1
35
3540-13251
• HOLDER(B)
1
36
6520-17100
HANGER ASSY
1
37
6520-17110
• HANGER
1
38
6520-17120
• CLAMP
1
39
6520-18130
• SPACER
1
40
0263-90525
• SCREW
1
41
T3112-12510
PLATE, name
1
42
T3112-12590
PLATE, number
1
43
6425-12552
PLATE, caution
1
44
T3112-14000
HANDLE ASSY
1
45
T3112-14110
• HANDLE
1
46
0263-90530
• SCREW
4
47
6489-24000
GUARD ASSY
1
48
6489-24110
• GUARD
1
49
6489-24200
• PLATE COMP
1
50
6489-24210
• • PLATE
1
51
6489-24220
• • BLADE
1
52
0277-10412
• • SCREW
1
53
6489-24120
• PLATE
1
54
01252-30516
• BOLT
4
55
01601-20513
• WASHER
4
56
3540-13283
COVER
1
57
6251-15910
COVER
1
58
T3300-17100
STRAP ASSY
1
59
6298-14343
SAW
1
60
T3112-18000
GRIP ASSY
1
61
K2300-000240
• GRIP (R)
1
62
K2300-000230
• GRIP (L)
1
63
K3200-000390
• CLAMP (A)
1
64
K3300-000010
• PLATE (A)
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
65
K3300-000020
• PLATE (B)
1
66
K5100-000240
• COLLAR
1
67
K5100-000220
• SPRING
1
68
K2300-000260
• SAFETY LEVER
1
69
K2300-000250
• THROTTLE LEVER
1
70
K3200-000400
• CLAMP (B)
1
71
K5100-000230
• SPRING
1
72
K5100-000210
• SPRING
1
73
K2300-000270
• PLATE
1
74
B1122-C2910H
• SCREW
1
75
K2300-000280
• SWITCH
1
76
K5200-000090
• CORD
1
77
K5100-000270
• CABLE COMP
1
78
K5100-000201
• • THROTTLE CABLE
1
79
K5200-000130
• • SLEEVE
1
80
K2300-000390
• LID
1
81
B1176-090530
• SCREW
4
82
B1181-04054606
• NUT
4
83
T3113-91000
TOOL KIT
1
84
1030-91340
• DRIVER
1
85
3144-91160
• SOCKET
1
86
09007-00425
• WRENCH
1
87
09007-00528
• WRENCH
1
88
3540-91110
• BAR
1
89
T3115-93110
MANUAL
1
Key# PART NUMBER
DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.1 CUTTER GROUP
BC3401DLM
