Fig. 2 carburetor components & accessories – Zenoah G2500 User Manual
Page 5
Q'TY
Key#
PART NUMBER
DESCRIPTION
NOTE
/UNIT
56
T2046-98120 • HANGER
1
OP
57
T2046-98130 • PLATE
1
OP
58
2630-33610 • SCREW
2
OP
59
T2046-32180 HANGER
1
OP
60
T2046-32190 PLATE
1
OP
61
T2046-32170 NUT
1
OP
62
2630-32170 SCREW
1
OP
63
2980-52111 BAR
1
OP
64 3622-52210-50 CHAIN, 25AP-60E
1
OP
65
2841-98301 ICING KIT
1
66
2841-98310 • PIPE
1
67
2841-98320 • CAP
1
68
2841-98330 • PROTECTOR
1
Q'TY
Key#
PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
848C128100 CARBRETOR ASSY
1
WT-747
2
3306-81380 • SCREEN
1
3
2630-81120 • COVER
1
4
3310-81130 • SCREW
1
5
3304-81140 • GASKET
1
6
1172-81150 • DIAPHRAM
1
7
3356-81310 • VALVE
1
8
2867-81270 • SPRING
1
9
3310-81250 • PIN
1
10
3310-81240 • SCREW
1
11
3310-81230 • LEVER
1
12
3310-81280 • COVER
1
13
1480-81420 • PLUG
1
14
2850-81290 • GASKET
1
15
3310-81260 • DIAPHRAM
1
16
1148-81390 • RING
1
17
3310-81341 • VALVE
1
18
2880-81470 • SCREW
3
19
2670-81410 • SPRING
1
20
T2040-81370 • SHAFT
1
21
2630-81330 • SCREW
1
22
3350-81380 • SPRING
1
24
2841-81440 • LEVER
1
25
2850-81190 • SCREW
1
26
2841-81451 • VALVE
1
27
2850-81350 • SPRING
1
28
2841-81460 • SHAFT
1
29
2850-81430 • BUSHING
1
30
3310-81351 • SCREW
4
35
T2100-06020 GASKET KIT
1
36
3320-91140 WRENCH
1
37
2670-91150 DRIVER
1
39 2475-52110-50 BAR 10" SP
1
40
3699-91480 CHAIN 91VG-40E
1
41
3622-52310 PROTECTOR
1
42
2475-98100 SPIKE KIT
1
OP
44
CB1011I BAR KIT
1
OP
45
2475-52120 • BAR, 10" CV
1
46 3622-52210-50 • CHAIN, 25AP-60E
1
48
2841-51110 • DRUM, 1/4-8T
1
49
3350-96220 STOPPER, PISTON
1
OP
50
3350-96240 GAUGE, AIR GAP
1
OP
51
3304-97611 WRENCH, HEXAGON
1
OP
52
2670-96410 WRENCH, TORX
1
OP
53
2841-96110 WRENCH, CLUTCH
1
OP
54
T2046-98100 BELT HANGER KIT
1
OP
55
T2046-98110 • HOOK
1
OP
Fig. 2 CARBURETOR COMPONENTS & ACCESSORIES
G2500
