Fig.1 power unit, G2500 – Zenoah G2500 User Manual
Page 3
Q'TY
Key#
PART NUMBER
DESCRIPTION
NOTE
/UNIT
86
2841-51230
• SPRING
2
87
2475-51240
• BOSS
1
88
2841-51210
PLATE
1
89
3310-51310
BEARING
1
90
848C1290F2
LABEL
1
91
2841-82510
ROD
1
92
2841-82411
ROD
1
93
2841-82421
GROMMET
1
94
848C128100
CARBRETOR ASSY
1
WT-747
95
2841-82210
SEAL
1
96
848C1083A3
PLATE
1
97
2841-82120
PLATE
1
98
0263-30545
SCREW
2
99
2841-83111
CLEANER
1
100
2841-83120
ELEMENT
1
101
2841-83303
COVER COMP.
1
102
2841-83320
• KNOB
1
103
2841-83330
• GROMMET
1
104
2630-53412
CATCHER
1
105
2630-32170
SCREW
1
106
848C106610
PLATE
1
107
848C1067D0
• SEAL
1
108
2841-75001
STARTER ASSY
1
109
2841-75101
• CASE COMP.
1
110
2841-75210
• REEL
1
111
2841-75300
• SPRING COMP.
1
112
1850-75160
• ROPE
1
113
3330-75421
• KNOB
1
114
1140-51230
• WASHER
1
115
2630-75510
• SCREW
1
116
2841-75611
• COVER
1
117
2841-75710
• PIPE
1
118
2630-31950
• SCREW
1
119
2630-31950
SCREW
4
120
2475-75131
LABEL
1
121
2475-54000
BRAKE ASSY
1
122
2475-54110
• COVER
1
123
2841-54121
• GUARD
1
124
2872-54120
• SPRING
1
125
0263-80530
• SCREW
1
126
2872-54140
• SPACER
1
127
2850-54211
• SPACER
1
128
848C605423
• WEIGHT
1
129
2841-54230
• SPRING
1
130
2851-54270
• SPRING
1
131
01641-20508
• WASHER
1
132
3310-53331
• NUT
1
133
2851-54301
• LEVER COMP.
1
134
2851-54350
• ROLLER
1
135
2670-54411
• ARM
1
136
2841-54510
• BAND
1
137
3356-24140
• ROLLER
1
138
2670-54610
• SPRLNG
1
139
2841-54620
• COVER
1
140
2630-33610
• SCREW
4
141
2841-53211
• PLATE
1
142
2841-53240
• SCREW
1
143
2810-53221
• NUT
1
144
2671-53230
• GEAR
1
145
3350-53410
NUT
1
146
2475-53121
LABEL
1
147
2841-32101
HANDLE ASSY
1
148
2841-32150
• STOPPER
1
149
2841-35110
• DAMPER
1
150
2630-75510
• SCREW
1
151
2630-75510
SCREW
2
152
848C103311
HANDLE COMP.
1
153
848C1033C3
• LEVER THROTTLE
1
154
3356-33321
• SPRING
1
155
04025-00524
• SPRING PIN
1
156
2841-35180
STOPPER
1
157
848C3033E3
ARM
1
158
2841-34110
COVER
1
159
2630-31950
SCREW
1
160
2841-35110
DAMPER
2
161
2841-35120
BOLT
3
162
2841-35150
CAP
3
163
2841-98210
HANGER
1
164
2630-33610
SCREW
1
165
2841-55220
SEAL
1
166
2850-21260
VALVE
1
167
2841-31410
SEAL
1
170
2670-14220
SCREW
1
Q'TY
Key#
PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
848C151211
CYLINDER COMP.
1
2
2841-12120
• ELBOW
1
3
2841-12210
PIPE
1
4
3310-82230
CLIP
1
5
3350-34320
ELBOW
1
6
2841-21110
CRANKCASE
1
7
T4950-52021
BOLT
4
8
2841-41112
PISTON
1
9
2841-41210
RING, piston
1
10
1600-41310
PIN
1
11
1260-41320
RING, snap
2
12
5500-41410
BEARING
1
13
1101-41340
WASHER
2
14
2841-42001
SHAFT COMP.
1
15
1155-21240
BEARING
2
16
T2041-21210
OIL SEAL
1
17
T2041-21220
OIL SEAL
1
18
1650-43230
NUT
1
19
1000-43240
KEY
1
20
2841-06011
PIPE SET
1
21
0263-30414
SCREW
2
22
T2041-15100
MUFFLER ASSY
1
23
T2046-15140
PLATE
1
24
2841-15210
GASKET
1
25
2670-82210
SCREW
2
26
2841-71102
ROTOR ASSY
1
27
2841-71120
• PAWL
2
28
T2044-71240
• SPRING
2
29
2850-71140
• SCREW
2
30
2850-71151
• WASHER
2
31
2841-71200
MODULE ASSY
1
32
2841-71220
• CORD
1
33
2616-71320
• CAP
1
34
2850-72110
• CAP
1
35
1400-72121
• SPRING
1
36
1140-72110
• GROMMET
1
37
5500-72150
SPACER
2
38
3350-14150
BOLT
2
39 3699-90032-10
SPARK PLUG
1
RCJ7Y
40
2850-74102
SWITCH ASSY
1
41
2850-74213
CORD
1
42
2841-74220
CORD
1
43
848C103111
CASE COMP.
1
44
2841-31141
• SCREW
2
45
2870-31750
SCREW
4
46
2475-31130
COVER
1
47
2630-31950
SCREW
2
48
2841-31202
PIPE ASSY
1
49
2841-31210
• PIPE
1
50
2841-31252
• GROMMET
1
51
1850-85300
• FILTER
1
52
2841-31280
• COLLAR
1
53
2850-34501
BREATHER ASSY
1
54
3317-85120
GROMMET
1
55
2850-81900
PUMP
1
56
2841-31260
PIPE
1
57
2841-31801
CAP ASSY
2
58
2841-31820
• GASKET
2
61
T2041-31910
COVER
1
62
2630-31950
SCREW
2
63
2841-31921
MAT
1
64
2841-37111
PIPE
2
65
2841-37121
PIPE
1
66
2841-37150
JOINT
2
67
2841-31300
PIPE COMP.
1
68
2841-31311
• PIPE
1
69
3310-57320
• JOINT
1
70
2841-31330
• PIPE
1
71
3310-57340
• CLIP
1
72
2670-23131
• FILTER
1
73
1260-41320
• RING
1
74
2841-55103
OIL PUMP ASSY
1
75
2841-55112
• OIL PUMP
1
76
2850-55121
• WORM
1
77
0263-30416
SCREW
2
78
2850-55211
WASHER
1
80
2841-55250
PIPE
1
81
2841-55310
COVER
1
82
2630-31950
SCREW
2
83
2475-51110
DRUM
1
3/8-6T
83
2841-51110
DRUM
1
1/4-8T
84
2475-51200
CLUTCH ASSY
1
85
2475-51220
• SHOE
2
Fig.1 POWER UNIT
G2500
