System Specifications
• work Standard: Netwo Ne
omePlug AV 200 Mbps data rate compliant Hom
• Power Line Network: Po
Supports up to 16 Powerline devices
communicating on a single network. Each
Powerline Ethernet adapter supports 15 remote
Ethernet addresses. With total 4 groups then it can
support up to total 64.
• Modulation:
OFDM Symbol Modulation, Supports QAM 1024/
256/64/16, DQPSK, DBPSK and ROBO Carrier
modulation schemes
• Frequency Band: 1.7 MHz ~ 30 MHz
• Coverage Area: up to 300 meters
• Security:
- 128 bit AES encryption
- Pushbutton Encryption
Hardware Specifications
• Interface: 10/100 Mbps Ethernet port with
MDI/MDIX
• One Power Input: 100-240 VAC, 50 ~ 60 Hz, 0.13 A
• LED Display on Top-Case
- Power
- Powerline Link and Activity
- Ethernet Link and Activity
Physical Specifications
• Dimensions: 112 (W) x 106 (D) x 28.5 (H) mm
• Weight: 185 g
Environmental Specifications
• Operating temperature: 0ºC ~ 40ºC
• Operating humidity: 20% ~ 95% RH
• Storage temperature: -20ºC ~ 60ºC
• Storage humidity: 20% ~ 95% RH
Certification
• Safety: UL/cUL, LVD
• EMI: CE, FCC part 15B
• HomePlug Certification: HomePlugAV
Specifications
Powerline Ethernet Adapter
PLA-400 v2
Application Diagram
Powerline
Adapter
VDSL2
ADSL2
Stereo
TV
Gaming
Internet
1
Ethernet
Extension 2
3 Network Backbone/
Contents Sharing Network Backbone/
Contents Sharing
less
erline Backbone
rnet
er Line
MI
F o r m o r e p r o d u c t i n f o r m a t i o n , v i s i t u s o n t h e w e b w w w . Z y X E L . c o m
65-100-040007B 10/07
