ZyXEL Communications PRESTIGE 660R-6XC User Manual
Page 2
P
P
r
r
e
e
s
s
t
t
i
i
g
g
e
e
F
F
r
r
o
o
n
n
t
t
P
P
a
a
n
n
e
e
l
l
L
L
E
E
D
D
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
LED
COLOR
STATUS
DESCRIPTION
Red
On
The power to the Prestige is too low.
On
The Prestige has a successful 10Mbps Ethernet connection.
Green
Blinking
The Prestige is receiving or sending data.
Amber
On
The Prestige has a successful 100Mbps Ethernet connection.
Blinking
The Prestige is receiving or sending data.
10/100M
Off
The LAN is not connected.
On
The Prestige is linked successfully to a DSLAM.
Blinking (Slow)
The Prestige is initializing the DSL line.
Blinking (Fast)
The Prestige is sending or receiving non-PPP traffic.
DSL/ACT Green
Off
The DSL link is down.
On
The Prestige has a PPP (PPPoA or PPPoE) connection.
Blinking
The Prestige is sending or receiving PPPoA or PPPoE traffic.
PPP Amber
Off
The Prestige does not have a PPP (PPPoA or PPPoE) connection.
Press the power switch in. The PWR/SYS LED blinks and turns steady on. The 10/100M and DSL
LEDs turn on, if they are properly connected.
P
P
r
r
e
e
s
s
t
t
i
i
g
g
e
e
F
F
a
a
c
c
t
t
o
o
r
r
y
y
D
D
e
e
f
f
a
a
u
u
l
l
t
t
s
s
LAN IP Address
192.168.1.1
Default Password
1234
Subnet Mask
255.255.255.0
DHCP IP Pool
192.168.1.33 – 192.168.1.64
I
I
n
n
t
t
e
e
r
r
n
n
e
e
t
t
A
A
c
c
c
c
o
o
u
u
n
n
t
t
I
I
n
n
f
f
o
o
r
r
m
m
a
a
t
t
i
i
o
o
n
n
Your ISP (Internet Service Provider) or telephone company should give you most of the following information or pre-
configured the Prestige with it when you signed up for your Internet access account. You do not need to know every field.
REQUIRED INFORMATION
Virtual Path Identifier (VPI): ____________
Virtual Channel Identifier (VCI): ____________
Multiplexing (VC-based or LLC-based):
VC
LLC
Your device’s WAN IP Address (if given): __________________
Encapsulation:
RFC 1483
ENET ENCAP
Ethernet Encapsulation Gateway IP Address: ____________________
PPPoA
User Name: ____________
Password: ____________
PPPoE
(PPPoE) Service Name: ____________
User Name: ____________
Password: ____________
