Page 27
81
I
cc
Control
Value [vv]
08H Dual Balance
00H : Left Voice Max.
7FH : Right Voice Max.
26H Touch Sensitivity
00H : Medium
01H : Soft
02H : Hard
59H Reverb
00H : Off
01H : Room
02H : Hall-1
03H : Hall-2
04H : Cosmic
5AH Dual Mode
00H : Dual Off
01H : Dual On (Normal)
02H : Dual On (Left voice 1 octave up)
03H : Dual On (Right voice 1 octave up)
5CH Dual Voice
[vv] : Dual Voice
PANEL DATA SEND FORMAT
F0H, 43H, 0nH, 7CH, 00H, 19H
(n: channel number)
53H, 4BH, 20H, 20H
(SK)
43H, 4CH, 50H, 31H, 32H, 32H
(CLP-122S)
3xH, 3yH
(x, y: version number)
[PANEL DATA]
[CHECK SUM (1byte)] = 0-(53H+4BH+20H+......+Data end)
F7H
• Panel Data Contents
(1) VOICE
(2) DUAL VOICE
(3) DUAL ON/OFF
(4) DUAL BALANCE
(5) 0
(6) 0
(7) 0
(8) REVERB NUMBER
(9) REVERB DEPTH
(10) TOUCH SENSITIVITY
(11) LEFT PEDAL (SOFT or SOSTENUTO)
(12) SPLIT POINT
(13) 0
MODEL ID CODE SEND FORMAT
F0H, 43H, 0nH, 7DH, 00H, 10H
(n: channel number)
53H, 4BH, 20H, 20H
(SK)
43H, 4CH, 50H, 31H, 32H, 32H
(CLP-122S)
3xH, 3yH, 20H, 20H, 20H, 20H
(x, y: version number)
[CHECK SUM (1byte)] = 0-(53H+4BH+20H+......+20H)
F7H
CLP-122S
KEYBOARD
88 KEYS (A-1 ~ C7)
VOICE SELECTORS
PIANO1, PIANO2, CLAVINOVA TONE, E. PIANO, HARPSICHORD, ORGAN
REVERB
ROOM, HALL 1, HALL 2, COSMIC
TOUCH SENSITIVITY
HARD, MEDIUM, SOFT
PEDAL CONTROLS
SOFT/SOSTENUTO, DAMPER
OTHER CONTROLS
MASTER VOLUME, MIDI/TRANSPOSE
JACKS/CONNECTORS
HEADPHONES
x
2, AUX. OUT R & L/L+R, OPTIONAL IN R/L, MIDI IN/OUT/
THRU
INPUT & OUTPUT
AUX. OUT: 600
Ω
LEVEL/IMPEDANCE
OPTIONAL IN: 15k
Ω
/-10 dBm (for nominal output level)
MAIN AMPLIFIERS
15W
x
2
SPEAKERS
16 cm
x
2
DIMENTIONS
(W x D x H)
1427.9
x
474
x
831.9 mm (56-1/4"
x
18-5/8"
x
32-3/4")
WEIGHT
50.5 kg (111.3 lbs.)
Specifications/Technische Daten/Caractéristiques techniques/Especificaciones
* Specifications subject to change without notice.
* Änderungen ohne Vorankündigung vorbehalten.
* Sous toute réserve de modification des caractéristiques sans préavis.
* Especificaciones sujetas a cambios sin previo aviso.
