Zenoah RS5B - Manual (Page 9)

1 5500-81002 CARBURETOR ASSY 1 WYJ-81C
2 1752-81110 • SCREW 2
3 5500-81120 • BRACKET 1
4 1751-81130 • E-RING 1
5 1881-81140 • SWIVEL 1
6 5500-81153 • VALVE ASSY 1
7 1918-81170 • SCREW,adjust 1
8 1751-81180 • NUT 1
9 1881-81130 • RING 1
10 1751-81240 • O-RING 1
11 5500-81251 • JET 1
12 3310-81260 • DIAPHRAGM 1
13 1065-81410 • GASKET,pump 1
14 1065-81420 • DIAPHRAGM,pump 1
15 1850-81450 • BODY ASSY 1
16 3306-81380 • • SCREEN 1
17 3356-81310 • • VALVE,inlet 1
18 1850-81270 • • SPRING 1
19 1850-81220 • • SCREW 1
20 3310-81250 • • PIN 1
21 3310-81230 • • LEVER 1
22 1850-81470 • GASKET 1
23 1850-81490 • BODY,air purge 1
24 1751-81510 • PUMP,priming 1
25 1850-81520 • COVER,pump 1
26 1850-81530 • SCREW 4
27 5500-81160 • WASHER 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.4 CARBURETOR GROUP
1 1110-91320 SOCKET 1
2 3582-91330 BAR 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.5 TOOL
RS5B
