Zenoah RS5B - Manual (Page 5)

1 2461-11110 SHAFT 1
2 2461-12220 IMPELLER 1
3 2461-11120 KEY 1
4 2461-11210 CASE,clutch 1
5 2461-12310 PIPE 1
6 2461-11220 CLIP 1
7 2461-11230 PROTECTOR 1
8 2461-12110 PUMP BODY 1
9 2461-12120 COVER 1
10 2461-11130 SCREW 4
11 2461-12210 O-RING 1
12 2461-12230 CLIP 1
13 2461-12240 COLLAR 1
14 2461-12250 SEAL 1
15 2461-12260 SCREW 7
16 2461-12270 SCREW 1
17 2461-12280 WASHER 1
18 2461-12310 PIPE 1
19 2461-12320 NUT 2
20 2461-12330 O-RING 2
21 2461-12340 SOCKET 1
22 2461-12350 PACKING 1
23 2461-12360 SOCKET 1
24 2461-12350 PACKING 1
25 2461-12370 CAP 1
26 2463-12650 PACKING 1
27 2463-25800 NOZZLE 1
28 2463-25850 COCK 1
29 2463-25860 PIPE 1
30 2463-25870 HOSE 1
31 2463-25880 PACKING 2
32 2463-25890 PACKING 3
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.2 PUMP and NOZZLE GROUP
RS5B
