26
In step 3, press the button (shown below) once or more so that
“6ch” appears on the display.
Discrete signals from the unit connected to the 6CH
DISCRETE INPUT terminals of this unit are selected as the
input signals. To cancel listening to a decoded source using Dolby
Digital (AC-3) or DTS
Press the same button again or select another input source.
Note for reproducing discrete signals with Dolby Digital
(AC-3) or DTS decoded:
1. Your speaker system must include a center speaker.
2. Your speaker system must include a subwoofer.
* Connect a subwoofer which has a built-in amplifier to the
SUBWOOFER OUTPUT terminal of this unit.
* You can do without using a subwoofer. If you do so, you
should make a setting for distributing signals at the LFE
channel to the right and left MAIN output terminals on the
Dolby Digital (AC-3) Decoder etc.
For details, refer to the owner’s manual for the Dolby
Digital (AC-3) Decoder etc.
Notes
● When you switch to the “6ch” mode, the built-in Digital
Sound Field processor will not work and adjustment of delay
time cannot be made.
● Switching this unit to the “6ch” mode will input no signal to
this unit if there is no connection to the 6CH DISCRETE
INPUT terminals of this unit.
RX-V393RDS
RX-V493RDS
DVD/LD TV/DBS
TAPE/MD MON 2CH/6CH
VIDEO VCR
2CH/6CH
DVD/LD TV/DBS
TAPE/MD MON 2CH/6CH
or
To listen to a decoded source using Dolby Digital (AC-3) or DTS by reproducing the signals
input to the 6CH DISCRETE INPUT terminals of this unit.
