For Europe use only

Min. size Cable/

Cable / flex type

Fuse

flex

1.5 mm

2

H07 RN-F, H05 RN-F, 13 A
H05 RR-F, H05 VV-F,
H05 V2V2-F (T90),
H05 BB-F

It is necessary that you install a double pole switch
between the oven and the electricity supply (mains),
with a minimum gap of 3mm between the switch
contacts and of a type suitable for the required load
in compliance with the current rules.
The switch must not break the yellow and green
earth cable at any point.
the yellow and green earth cable should be 2-3 cm
longer than the other cables.
Important
After installation and connecting, the cable must be
placed so that it cannot at any point reach a
temperature of more than 60°C above the ambient
temperature.
Before the oven is connected, check that the main
fuse and the domestic installation can support the
load and that the power supply is properly earthed.

The manufacturer declines any responsibility
should these safety measures not be carried
out.

Electrical connection

The oven is designed to be connected to 230 V (50 Hz)
electricity supply.
The oven has an easily accessible terminal block
which is marked as follows:
Letter L

-

Live terminal

Letter N

-

Neutral terminal

or E

-

Earth terminal

THIS OVEN MUST BE EARTHED

The cable used to connect the oven to the electrical

supply must comply to the specifications given

below.

Connection

Min. size

Cable / flex

Fuse

via

Cable/flex

type

13 A socket

2.5 mm

2

3 core

13 A min.

outlet

butyl

13 A spur box

insulated

Oven

2.5 mm

2

PVC/PVC

15 A min.

Control

twin and

Circuit

earth

20 A max.

For UK use only
