Fig.2 ENGINE GROUP BC2601DL

Key#

Description

Part Number

Q'ty

1

CYLINDER

5911-12110

1

2

GASKET, base

5500-12212

1

3

BOLT

1850-12130

2

4

INSULATOR

1920-13162

1

5

GASKET, insulator

5500-13121

1

6

GASKET, carburetor

5500-13131

1

7

SCREW

0263-90520

2

8

MUFFLER ASS'Y

5850-15100

1

9

• ARRESTER

1601-15120

1

10

BOLT

01252-30550

2

11

GASKET, muffler

5910-15211

1

12

PLATE, muffler

5500-15220

1

13

SCREW

0263-90416

1

14

CRANKCASE COMP.

5500-21100

1

15

• PIN

2629-21130

3

16

GASKET, case

5500-21141

1

17

BEARING

06030-06001

2

18

OIL SEAL

2169-21210

1

19

OIL SEAL

1850-21220

1

20

SNAP RING

04065-02812

1

21

SCREW

01252-30530

4

22

PISTON

5910-41110

1

23

RING

5910-41210

2

24

PIN

1600-41310

1

25

SNAP RING

1260-41320

2

26

BEARING

1140-41330

1

27

WASHER

1101-41340

2

28

CRANKSHAFT COMP.

5500-42001

1

29

NUT

1650-43230

1

30

KEY

1000-43240

1

31

SHOE, clutch

1140-51111

2

32

SCREW

1140-51250

2

33

SPRING

1970-51221

1

34

WASHER

1140-51230

2

35

WASHER

1970-51241

2

36

ROTOR

5501-71110

1

37

COIL ASS'Y

5501-71201

1

38

• CORD

5500-71220

1

39

• CAP

2616-71320

1

40

CAP, plug

1900-72111

1

41

SPRING

1900-72120

1

42

GROMMET

5500-72130

1

43

SPACER

1260-71261

2

44

BOLT

3310-72150

2

45

RECOIL ASS'Y

5500-75100

1

46

• CASE COMP.

5500-75110

1

47

• REEL

1850-75120

1

48

• SPRING, spiral

1850-75130

1

49

• SCREW

1850-75151

1

50

• ROPE

1850-75160

1

51

• KNOB

1140-75320

1

52

• PLATE, stopper

5500-75170

1

53

PULLEY ASS'Y

1850-75201

1

54

• RATCHET

1850-75221

1

55

• SPRING

1850-75230

1

56

SCREW

0263-90416

4

57

CARBURETOR ASS'Y

5911-81000

1

58

• SCREW

1752-81110

2

59

• BRACKET

5500-81120

1

60

• RING

1751-81130

1

Key#

Description

Part Number

Q'ty

61

• SWIVEL

1881-81140

1

62

• VALVE ASS'Y

–––––––––

1

63

• SCREW, adjuster

1918-81170

1

64

• NUT, adjuster

1751-81180

1

65

• RING

1881-81130

1

66

• O-RING

1751-81240

1

67

• JET

5500-81251

1

68

• Rebuilt Kit

5602-06030

1

69

• • Body ASS’Y

1850-81450

1

70

• • • Screen

–––––––––

71

• • • Valve

–––––––––

72

• • • Spring

–––––––––

73

• • • Screw

–––––––––

74

• • • Pin

–––––––––

75

• • • Lever

–––––––––

76

• • Gasket kit

5602-06020

1

77

• • • Washer

–––––––––

78

• • • Gasket, pump

–––––––––

79

• • • Diaphragm, pump

–––––––––

80

• • • Gasket, diaphragm

–––––––––

81

• BODY, purge

1850-81490

1

82

• PUMP, priming

1751-81510

1

83

• COVER, pump

1850-81520

1

84

• SCREW

1850-81530

4

85

• WASHER

5500-81160

1

86

SCREW

0263-30555

2

87

BODY ASS'Y

5500-82102

1

88

• SLEEVE

1970-82190

2

89

• PLATE, choke

5500-82131

1

90

• LEVER, choke

5500-82140

1

91

• SCREW

2630-33610

1

92

ELEMENT

5500-82171

1

93

COVER ASS'Y

5600-82202

1

94

• KNOB

5500-82221

1

95

• RING

5500-82230

1

96

COVER, fan

5501-31111

1

97

SCREW

0263-90520

4

98

COVER, engine

5580-32112

1

99

SCREW

1850-32160

1

100

SCREW

1900-31410

2

101

GUARD, plug

5500-32210

1

102

SCREW

0263-90514

1

103

SPARKPLUG

5602-73110

1

104

GROMMET

1852-72121

1

105

CORD COMP.

5500-73201

1

106

TANK ASS'Y

5911-85002

1

107

• CAP ASS'Y

5601-85200

1

108

• • HOLDER

5601-85230

1

109

• • CAP, holder

5600-85240

1

110

• • VALVE

5600-85250

1

111

• • PACKING

5500-85220

1

112

• PIPE COMP.

5911-85300

1

113

• FILTER ASS'Y

5500-85400

1

114

• CLIP

1260-85460

1

115

SCREW

5500-85510

2

116

SCREW

5910-85510

1

117

CLIP

1950-86120

1

118

LABEL

T1077-91120

1

119

STAND

1897-31911

1

120

CLAMP

1140-72231

1
