ZyXEL 1000 Mbps SFP Transceiver Family
Model
Laser Transmitter Characteristics
Maximum Launch Power
Minimum Launch Power
Receiver Characteristics
Optical Receiver Sensibility
Maximum Input Power
Optical Budget
Wavelength
Connector
Transmission Distance vs Fiber Cable Specification
62.5 um MMF
50 um MMF
9 um SMF
Operational Ranges
Supply Voltage
Max Current
Dimensions (mm)
-3 dBm
-9.5 dBm
-20 dBm
-3 dBm
10.5 dB
1310 nm
LC
220 m
550 m
10 km
3.1 ~ 3.5 V
300 mA
56 x 13.4 x 12.4
SFP-LHX1310-40
+3 dBm
-2 dBm
-23 dBm
-3 dBm
21 dB
1310 nm
LC
N/A
N/A
40 km
3.1 ~ 3.5 V
300 mA
56 x 13.4 x 12.4
SFP-ZX-80
+5 dBm
0 dBm
-24 dBm
-3 dBm
24 dB
1550 nm
LC
N/A
N/A
80 km
3.1 ~ 3.5 V
300 mA
56 x 13.4 x 12.4
SFP-BX1490-10
-3 dBm
-9 dBm
-20 dBm
-3 dBm
11 dB
1490 nm (TX)
1310 nm (RX)
LC
N/A
N/A
10 km
3.1 ~ 3.5 V
300 mA
56 x 13.4 x 12.4
SFP-SX
-4 dBm
-9.5 dBm
-17 dBm
-3 dBm
7.5 dB
850 nm
LC
220 m
550 m
N/A
3.1 ~ 3.5 V
250 mA
56 x 13.4 x 12.4
SFP-BX1310-10
-3 dBm
-9 dBm
-20 dBm
-3 dBm
11 dB
1310 nm (TX)
1490 nm (RX)
LC
N/A
N/A
10 km
3.1 ~ 3.5 V
300 mA
56 x 13.4 x 12.4
Hardware Specifications
• Support of auto-negotiation
• Support of auto MDI/MDI-X
ES-1528
• Ports: 24 10/100Base-T, RJ-45 ports,
2 1000Base-T ports and 2 SFP open slots
ES-1552
• Ports: 48 10/100Base-T, RJ-45 ports,
2 1000Base-T ports and 2 SFP open slots
Power Requirements
• Input voltage of AC: 100-240 VAC, 50/60 Hz
• Max power rating of AC: 11.6 Watt (ES-1528)
• Max power rating of AC: 20.5 Watt (ES-1552)
Physical Specifications
ES-1528
• Dimensions: 441 (W) x 132 (D) x 44 (H) mm
• Weight: 1.95 kg
ES-1552
• Dimensions: 441 (W) x 197 (D) x 44 (H) mm
• Weight: 2.7 kg
Environmental Specifications
• Operating temperature: 0 °C ~ 45°C
• Storage temperature: -10 °C ~ 70°C
• Operating humidity: 10% ~ 90%,
(non-condensing)
Certification
• EN 60950-1
• IEC 60950-1
