Zanussi BCF64A - Manual (Page 2)

ACTIVE BLAST CHILLER / FREEZERS
56 KG - 20 GN 1/1
DCB03 2011-06-10 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L TROLLEY FOR 20X1/1 ROLL-IN RACK 922132
RILSAN COATED GRID 881061
REMOVABLE TRAY SUPPORT RACK FOR 20 GN1/1 881010
RACK RAILS FOR VERTICAL BLAST CHILLER 881182
PRINTER HACCP BASIC VERS-REF.ELECR.CONTR 881532
PLASTIC COATED GRID-600X400 MM 880864
PAIR OF 1/1 GN AISI 304 S/S GRIDS 921101
KIT HACCP ADVANCED CONNECT. BC/BCF LW+CW 880183
80MM PITCH ROLL-IN RACK 14X1/1GN 922205
60-MM PITCH ROLL-IN RACK FOR 20X1/1 922203
3-POINT-SENSOR PROBE-BL.C/FREEZERS LW 880212
1 SINGLE-SENSOR PROBE-BL.C/FREEZERS LW 880213
BCF64A
110723
ACCESSORIES MODELS
OPTIONAL ACCESSORIES
�
The control unit provides several
operating settings: time/core
temperature according to NF and UK
regulations, time/air
temperature/probe personalised
according to national regulations,
sterilizing cycle: UV lamps built-in
(on request), 3 single sensor or
3-sensor temperature probes (as
accessory), ideal for meats,
automatic defrosting and manual
defrosting. All parameters are
programmable.
�
The control unit provides two large
displays to read out: time, core
temperature, residual time, alarms,
service information.
�
Two customizable cycles for each
operating modes, allowing setting
time and air temperature. These two
programs (P1-P2) can be converted
into ice-cream specialist cycles
(shape maintenance and holding).
�
All information related to the
different operating models are
recorded: date, time, cycle, core
temperature, holding temperature,
HACCP accordance.
�
An audible alarm starts when the
cycle ends or terminates abnormally.
� Chilling times can vary according
to food quantity, density, moisture
contents and type of containers.
�
Internal and external finishing in
304 AISI stainless steel and
backpanel in galvanized steel.
� HCFC, CFC and HFC free
insulation (Cyclopentane), HCFC
and CFC free refrigerant gas
(R404a).
�
Developed and produced in ISO
9001 and ISO 14001 certified
factory.
�
Inner cell with rounded corners.
�
Door equipped with removable
magnetic gasket with hygienic
design.
� Evaporator with antirust
protection.
�
Ventilator swinging panel foreasy
access to the evaporator.
�
Automatic heated door frame.
�
Hot gas defrosting system.
�
Thermostatic expansion valve to
optimize the cooling unit efficiency.
�
Adjustable feet 150 mm high.
� Stand alone printer as accessory.
� PC connection as accessory, gate
RS 485. No water connections
required: Waste water can be
plumbed into drain, but can also be
collected in an optional waste
container.
