22
SECTION 11: PARTS LIST
Ref.
No.
Part No. Description
1 731-1869 Steering Wheel: 4 Spoke
2 731-1904 Steering Wheel Cap
2
1
Ref.
No.
Part No. Description
1 731-1877 Steering Column: Black
2 731-1918 Control Knob
3 712-0142 Hex Nut 8-32
4 710-3217 Pan Head Machine Screw #8-32
5 710-0599 Hex Screw TT 1/4-20 x .50”
6 710-0514 Hex Screw 3/8-16 x 1.0”
7 712-0431 Lock Nut
8 749-1099 Bumper Tube*: Front
2
4
3
1
5
6
5
8
7
7
NOTE: For painted parts, please refer to
the list of color codes below. Please add
the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part
numbered 700-xxxx is painted Yard-Man
Green, the part number to order would be
700-xxxx-0665.
Yard-Man Green: 0665
Yard-Man Yellow: 0674
Powder Black: 0637
* If equipped
