12
Monitor Installation
- It is recommended that this product only be used at an altitude of less than 6562 feet
(2000m) to get the best quality picture and sound.
- This plasma display is designed to be mounted horizontally (wide viewing).
- Your P60W26 (Monitor) can be installed on a wall as shown below, or on a desktop
pedestal as shown on the next page. Wall mount and stands are optional, and are not
supplied with the monitor.
Wall Mount Installation
,,,,,,
,,,,,,
,,,,,,
,,,,,,
• The monitor can be installed on the wall as shown above.
(For further information, refer to the optional ‘(Tilt) wall mounting bracket
Installation and Setup Guide’.)
• Speakers are optional, and shown for illustration only.
Tips
• Install this monitor only in a location where adequate ventilation is available.
4inch
4inch
4inch 4inch
1.18inch
a.
( Wall mount minimum
allowable clearances
for adequate ventilation )
