1. Oven Thermostat Pilot Light
2. Cooker Operation Pilot Light
3. Front left hotplate control knob
4. Back left hotplate control knob
5. Back right hotplate control knob
8 7 6 5 4
2
1 3
Control Panel
The Oven Cavity
Grill element Oven Light
Accessories
Oven fan
9
Grill trivet
Grill/roasting pan
Removable
handles
Fitting the Splash back
A stainless steel splash back is supplied with the
appliance. This is meant to be fitted on the rear edge of
the cooker's hob. The splash back package is in the
oven cavity.
1. Unpack the splash back and dispose of the packaging
with due regard to safety and the environment.
2. Slide the two bayonets of the splash back into the
relevant supports on the rear edge of the cooker's
hob.
6. Front right hotplate control knob
7. Oven function control knob
8. Oven thermostat control knob
9. 24 hour clock and Timer
