Model series 520 – Yard Machines 330 User Manual
Page 23
23
Model Series 520
REF.
NO.
PART NO.
DESCRIPTION
1
647-0004
Control Handle Ass’y. (Deluxe)
747-0824
Control Handle Ass’y. (Std.)
2
720-0225
Foam Grip (Optional)
3
749-0539B
Upper Handle
4
710-0605
Oval C-Sunk Scr.
5
646-0875
Throttle Body
6
746-0550
Control Cable—39" Lg.
7
736-0501
Spring Wash. .66" I.D.
8
712-0324
Hex L-Nut 1/4-20 Thd.
9
731-0620
Control Lever
10
731-1057
Control Cover Half—Upper
11
731-1058
Control Cover Half—Lower
12
746-0710A
Self-Propelled Cable—48" Lg.
13
731-1059
Cable Mounting Cap
14
710-0841
Fl-‘‘C’’ Sunk Hd. Tap Scr.#10 x .75" Lg.
15
710-1174
Curved Hd. Bolt 5/16-18 x 2" Lg.
16
712-0267
Hex Nut 5/16-18 Thd.*
17
720-0279
Handle Knob 1/4-20 Thd.
18
710-1205
Rope Guide
19
726-0240
Cable Tie
20
749-0734B
Lower Handle
21
14967
Wheel Cover
22
—
Engine
23
710-3015
Hex Bolt 1/4-20 x .75" Lg. (Gr. 5)
24
736-0270
Bell-Wash. 1/4" I.D.
25
748-0312
Wheel Ratchet
26
748-0315
Pawl and Spring Ass’y.
27
712-0329
Special Hex Nut 5/16-18 Thd.
28
741-0485
Flange Bearing .63" I.D.
29
734-1399
Rim Ass’y. Only 16" x 2.1"
30
734-1400
Rimstrip 16" x 7/8"
31
734-1397
Inner Tube 16" x 2.12"
32
734-1396
Chevron Tire 16" x 2.125"
33
736-0104
Intern. L-Wash. 5/16" I.D.
34
710-0376
Hex Bolt 5/16-18 x 1.0" (Gr. 5)
35
735-0639
Spark Plug Boot (Optional)
36
753-0588
Blade Adapter Kit
37
742-0742
22" Mulching Blade
742-0642
22” Blade (Std.)
38
736-0524A
Blade Bell Support
39
710-1044
Hex Bolt 3/8-24 x 1.5" Lg.
43
756-0962
Upper Pulley Half
44
736-0514
Fl-Wash. .88" I.D.
45
748-0358
Crankshaft Spacer
46
741-0484
Ball Bearing 1/2" I.D. (Optional)
47
736-0105
Bell-Wash. .38" I.D.
48
738-0507B
Shld. Bolt .5"
49
14832
Spring Lever Ass’y. w/Knob
50
15262B
Pivot Bar
51
15261A
Height Adj. Plate
52
**
Wheel Ass’y. Comp.
53
14578
Height Adj. Ass’y. Comp.—R.H.
14579
Height Adj. Ass’y. Comp.—L.H. (Not
Shown)
54
736-0356
Bell-Wash. .39" I.D. x 1.38"
55
712-0798
Hex Nut 3/8-16 Thd.*
56
682-0001A
22" Deck Ass’y.
57
731-1034
Chute Deflector Ass’y.
58
747-0710
Hinge Pin
59
732-0593
Torsion Spring
60
17032
Adapter Plate
61
710-0599
Hex TT-Tap Scr. 1/4-20 x .5"
62
736-0504
Wave Wash. .51" I.D. x .78"(Used w/Ref. 46)
63
†
Hub Cap (Optional)
64
710-0654A
Hex TT-Tap Scr. 3/8-16 x 1"
65
710-0260
Carriage Bolt 5/16-18 x .62" Lg.
66
16136C
Handle Brkt. Ass’y.—R.H.
67
750-0624
Shld. Spacer .5" x .10"
68
736-0242
Bell-Wash. 5/16" I.D.
69
714-0104
Intern. Cotter Pin 5/16" Dia.
70
16563A
Retaining Strip
71
731-1172
Rear Flap
72
811-00185
Throttle Box Comp. (Incl. Ref. 4,5, 7, 8, 98)
73
738-0102
Front Axle Bolt
74
720-0223
Grip
75
732-0655
Height Adjustment Lever
76
682-3004
Handle Brkt. Ass’y.—L.H.
77
754-0369
‘‘V’’ Belt
78
717-0417B
Transmission Comp.(See Breakdown)
79
710-0653
Hex Tap Scr. 1/4 x .38" Lg.
80
710-0896
Hex Tap Scr. 1/4 x .62" Lg.
81
736-0329
L-Wash. 1/4" I.D.*
82
712-0287
Hex Nut 1/4-20 Thd.*
83
734-1398
Wheel Ass’y. Comp.
84
713-0425
Sprocket and Axle Ass’y.
85
736-0256
Fl-Wash. .635" I.D. x 1.0" O.D.
86
682-7501
Chaincase and Arm Ass’y.
87
713-0257
#48 Chain 1/2" Pitch x 52 Links
88
682-7500
Rear Drive Support Ass’y.
89
710-0599
Hex Wash. Hd. TT-Tap Scr.1/4-20 x .5"
90
746-0843
Throttle Cable
91
16500A
Hex Bearing Cup
92
741-0413
Hex Flange Brg. .631" I.D.
93
748-0313
Spacer .63" I.D. x 1.25"
94
736-0300
Fl-Wash. .385" I.D. x .87" O.D.
95
712-0296
Hex L-Nut 3/8-24 Thd.
96
710-0870
Hex Bolt 3/8-16 x .625" Lg.
97
712-0431
Flanged L-Nut 3/8-16 Thd.
98
746-0876
Throttle Lever
99
710-0607
Hex B-Tap Scr. 5/16-18 x .5"
100 710-3013
Hex Bolt 1/4-20 x .5" Lg.
101 736-0302
Fl-Wash. .632" I.D. x .943"
102 750-0192
Spacer .635" I.D. x .88" x .790
103 736-0513
Spr. Wash. .89" I.D.
104 736-0258
Fl-Wash. .38" I.D. x 1" O.D.
105 710-1237
Wash. Hd. Scr. #10-32 x .62" Lg.
106 751B213146
Casing Clamp
107 756-0961
Lower Pulley Half
108 782-9014
Deck Bracket
109 720-0276
Hand Knob
110 731-1386A
Mulching Baffle (Optional)
111 750-0471
Spacer
REF.
NO.
PART NO.
DESCRIPTION
