Hotspot/Service Gateway Series
Model Name
G-4100 v2 N4100 VSG-1200 V2
Product Picture
Main Design
Wireless Technology 802.11b/g 802.11b/g/n -
Number of 10/100M LAN/Switch 4 4 1
WAN 1 1 1
Auto MDI-MDIX Yes Yes Yes
RS-232 Interface For Engineering Only - 2 (Console/PMS/Manufacture)
Account Generator Printer SP300E (Ethernet) SP300E (Ethernet) SP300E (Ethernet)
No. of SP300E Ticket Printers 10 10 10
Reset Factory Default Button Yes Yes Yes
PoE Yes - -
PoE Power Draw 6 W - -
WLAN Features (G-4100 v2 and N4100 only)
Number of Antenna 2 3Tx3R MIMO -
Maximum Throughput 22 ~ 24 Mbps 150 Mbps -
Range
Open space: 100 ~ 300 m Open space: 100 ~ 300 m -
Indoors: 35 ~ 100 m Indoors: 35 ~ 100 m
WEP Data Encryption Yes (64/128) Yes (64/128) -
WPA Data Encryption (Wi-Fi Certified) Yes (TKIP) Yes (TKIP) -
WPA2 Data Encryption (Wi-Fi Certified) Yes (AES) Yes (AES) -
Power Requirement
External Power Adapter External Power Adapter
Power Supply
Input: 100-240 V AC, Input: 100-240 V AC,
100-220 V AC, 50/60 Hz
50/60 Hz, 0.35 A 50/60 Hz, 0.5 A
Output: 5 V, 2 A Output: 12 V, 1.5 A
Environmental Specification
Operating Temperature 0 °C to 50°C 0 °C to 50°C 0 °C to 50°C
Storage Temperature -20 °C to 60°C -20 °C to 60°C -20 °C to 60°C
Operating Humidity 10% to 90%, (non-condensing) 10% to 95%, (non-condensing) 10% to 95%, (non-condensing)
Physical Feature
Dimensions (W) x (D) x (H) mm 213 x 139 x 52 222 x 146 x 35 440 x 116 x 44
Weight 508 g 565 g 1.7 kg
Certifications
FCC, VCCI, CE, R&TTE, CSA, FCC, CE, C-Tick, NCC,
FCC/VCCI/CSA/CE/RoHS/WEEE
C-Tick, RoHS, WEEE RoHS, WEEE
Specifications
The ZyXEL Hotspot/Service Gateway Series includes two parts: WLAN Hotspot Gateway and Vantage Service Gateway to meet various needs.
WLAN Hotspot Gateway
The ZyXEL WLAN Hotspot Gateway consists of two models: G-4100 v2 and N4100. The G-4100 v2 and N4100 are all-in-one hotspot gateways providing
a fully flexible solution with support for the IEEE 802.11b/g/n (G-4100 v2 supports 802.11g while N4100 supports 802.11n) wireless standards. They are
designed to work as access controllers for service providers/hotspot operators and hospitality businesses to deliver hotspot services.
Vantage Service Gateway
The VSG-1200 V2 Vantage Service Gateway is a freestanding or rack-mountable service gateway with a built-in authentication server to provide access
to the Internet for large hospitality facilities.
