Model Name
Switch 7000 Series
MS-7206
System Capacity
• Switch Fabric Slot: 2
• I/O Module Slot: 4
• Power Supply Unit Slot: 2
• Fan Module Slot: 1
Performance
• Switching Fabric: 384 Gbps
• Forwarding Rate: 285 Mbps
Max Port Density
• 1000BASE-T: 192
• 1000BASE-T with PoE: 192 (4 x MI-7248PWR)
• 1000 SFP: 96
• 10G: 32 (4 x MI-7308 + 8 EM-412/EM-422)
Resilience and
Availability
• IEEE 802.1D STP/802.1w RSTP/802.1s MSTP
• Redundant Power supply support
• IEEE 802.3ad LACP(max # trunks/links per trunk): 6/8
• Switch Fabric High Availability
• VRRP
• MRSTP
• Dual Configuration Files
• Swappable Fan module
Traffic Control
• 256 static VLAN up to 4K dynamic VLAN
• 802.1ad VLAN Stacking (QinQ)
• BPDU Transparency
• GVRP
• VLAN Trunking
Security
• 802.1x
• Intrusion Lock
• MAC Filtering • MAC Freeze
• Port Isolation
• Port Security • SSH v1/v2
• SSL
• Static MAC Forwarding
• ACL (L2/L3/L4) Security Filtering
Management
• iStacking
• Web Interface
• CLI
• Syslog
• Daylight Saving • RMON (1, 2, 3, 9)
• Port Mirroring
• NTP
• DHCP Relay per VLAN
• RJ-45 Out-of-band Management Port • DHCP Option 82
• DHCP Client (Management)
• RS-232 Out-of-band Console Port
• SNMP v1, v2c
• 802.3af PoE Support
• Jumbo Frame Support on Gigabit ports
Dimensions
(W x D x H mm)
435 x 316 x 447
Power Consumption
(Watt)
583
Module
MM-7201 Management Switching Fabric Module
MI-7248 48-port 100/1000BASE-T (RJ-45) I/O Module
MI-7248TF 48-port (24 RJ-45 and 24 SFP Slot) GbE Ports I/O Module
MI-7248PWR 48-port 100/1000BASE-T (RJ-45) I/O Module with PoE (Full Power)
MI-7308 4-port XFP and 2 Expansion Slot (EM-412/EM-422) I/O Modules
Module
(Power Supply) MP-7201 600 W Power Supply Module
MP-7202 750 W External PoE Power Souring Device
Model Name
Switch 4500 Series Switch 4000 Series Switch 3000 Series
XGS-4528F GS-4024 ES-4124 ES-3124 ES-3124PWR ES-3148
Port Density
10/100Base-TX,
RJ-45 Ports
24 24 48
10/100Base-TX PoE 24
1000Base-T,
RJ-45 Ports
20 2 2 2 2
Dual Personality
GbE Ports
24 4 2 2 2 2
10G Extend Slot 1
12G Stacking Port 2
Performance
Switching Capacity 144 Gbps 48 Gbps 12.8 Gbps 12.8 Gbps 12.8 Gbps 17 Gbps
Switching
Forwarding Rate
100 Mpps 35.7 Mpps 9.6 Mpps 9.6 Mpps 9.6 Mpps 13.1 Mpps
Packet Buffer 768 K 2 MB 32 MB 32 MB 32 MB 32 MB
MAC Address 8 K 16 K 16 K 16 K 16 K 16 K
Reliance and Availability
STP/RSTP/MSTP Yes Yes Yes Yes Yes Yes
Dual Configuration
Files
Yes Yes Yes Yes Yes Yes
IEEE 802.3ad LACP Yes Yes Yes Yes Yes Yes
Redundant Power
Supply Support
Yes Yes Yes Yes Yes Yes
MRSTP Yes Yes Yes Yes Yes Yes
VPRP Yes Yes
Loop Guard Yes Yes Yes Yes Yes Yes
Traffic Control
All Series Support
• Static VLAN/
Dynamic VLAN
• 802.1ad VLAN
Stacking (QinQ)
• BPDU
Transparency
• 802.1Q Port
Base VLAN
• IP Subnet
Based VLAN
• VLAN Trunking
• GVRP
Security
All Series Support
• 802.1x
• Port Security
• MAC Filtering
• MAC Freeze • SSHv1v2
• SSL
• Intrusion Lock
• Static MAC Forwarding • MAC Authentication
• Port Isolation
• IP Source Guard
• ACL (L2/L3/L4) Security Filtering
Management
All Series Support
• CLI
• iStacking
• RMON (1, 2, 3, 9)
• SNMP v1, v2c, v3
• Daylight Saving
• NTP • SNMP Trap Group
• DHCP Option 82
• Port Mirroring
• Web Interface
• Syslog
• TACACS+ Accounting • TACACS+ Authentication
• DHCP Relay per VLAN
• RADIUS Accounting
• RS-232 Out-of band Console Port
• 802.3ah OAM
• Jumbo Frame Support on Gigabit ports
• RJ-45 Out-of-band Management Port
Environmental Specification
Dimensions
(W x D x H mm)
438 x 310 x 44.45 438 x 300 x 44.45 438 x 225 x 44.45 438 x 270 x 44.45 438 x 420 x 44.45 438 x 300 x 44.45
Power Consumption
(Watt)
62.8 53.8 30.3 28.7 437 39.7
LAN Switches Feature Matrix
