Page 29 Condensed Catalog
3000 Series Architectural Door Closers offer the perfect combination of reliability,
appearance and durability in today’s market.
• Non-handed
• Staked valves
• Standard, separate and independent, latch, sweep and backcheck intensity valves
• 2-1/8" (54mm) projection (standard covers)
• All standard arm applications allow doors to swing 180°, conditions permitting
• 3300/3301 shipped with slim-line plastic covers
• 3500/3501 shipped with full cover
• Metal, architectural plastic or architectural metal covers (3500 or 3501 only)
• Delayed action
• Heavy-duty arms available: Parallel Rigid, Holder/Stop, Holder/Stop Spring and UNI Stop™
• Certified ANSI/BHMA A156.4, Grade 1
• UL listed
• UL10C compliant for positive pressure
• ADA compliant (3301 and 3501)
DOOR CONTROLS
3000 SERIES
3300 3500 3301 3501
Sized springs 2,3,4,5,6 with 50% additional adjustment X X
Adjustable spring sizes 1 through 6 X X
Bi-pack standard (regular arm and top jamb mounting) X X
Tri-pack standard (regular arm, top jamb or parallel arm
mounting)
X X
FEATURES
OPTIONAL FEATURES
COMPLIANCE STANDARDS
