Fig.3 ENGINE (1)
eHT750S / eHT600D
Q’TY
Key# PART NUMBER
DESCRIPTION
NOTE
/UNIT
1
T1600-12110 CYLINDER
1
2
5500-12213 GASKET
1
3
1850-12130 BOLT
2
4
T1650-21100 CRANKCASE COMP
1
5
2629-21130 • PIN
3
6
T1600-21140 GASKET, case
1
7
T1600-21240 BEARING
2
8
T1600-21210 SEAL
1
9
T1600-21220 SEAL
1
10
04065-02612 RING
1
11
01252-30520 BOLT
3
12
T1650-42003 CRANKSHAFT COMP
1
13
1160-41110 PISTON
1
14
1100-41210 RING
1
15
1101-41310 PIN
1
16
1260-41320 RING
2
17
5500-41410 BEARING
1
18
1101-41340 WASHER
2
19
T1600-15110 MUFFLER
1
20
01252-30550 BOLT
2
21
T1650-15210 GASKET
1
22
T1650-13100 INSULATOR COMP
1
23
0282-10604 • NUT
1
24
T1600-13170 • ADJUST SCREW
1
25
5500-13121 GASKET
1
26
5500-85510 SCREW
2
27a
T1650-71110 ROTOR
1
eHT750S
27b
T1600-71111 ROTOR
1
eHT600D
28
T1650-71200 COIL ASS'Y
1
29
T1600-72110 • CAP
1
30
T1600-72120 • SPRING
1
31
3350-14150 BOLT
2
32
1260-71261 SPACER
2
33
T1600-73200 CORD COMP
1
34
2750-32620 NUT
1
35
T1650-72140 CAP
1
36
1881-73110 SPARKPLUG (Champion)
1
CJ-6Y
37
T1650-51100 CLUTCH ASS'Y
1
38
T1650-51110 • SHOE, clutch
2
39
T1650-51230 • SPRING
2
40
T1650-51210 • BOSS
1
