VoIP Station Gateway
p-2304r-p1
Hardware
•
s
Built-in TWO Auto MDI/
0/100M RJ-45 Ports
I/MDI-X 10
10/
for LAN & WAN
•
SLIC)
4 FXS POTS Interface for A
ephone (SL
r An
nalog Telep
• Restore Factory Default
on
ults/Reb
boot Butto
Router Features
• NAT (Includes
es Multi-to-m
SUA
o-multi NAT)/S
• NAT Server
r (Port Forw
N
orwarding)
• CP/IP
TCP
•
oE Client
PPPo
•
Client
DHCP C
nt/Serrver
•
P
P
RIP I/RIP
P II Support
rted
•
Multicas
IP Mu
asting, IGMP
MP v1 and v2
•
Dynamic DN
Dy
NS Support
rt
•
•
IP Alias
Voice Functionality
• SIP (RFC 3261) v2
• SDP (RFC 2327)
• RTP (RFC 1889)
• RTCP (RFC 1890)
•
n: G.168
Echo Cancellation
•
ivity Detection)
VAD (Voice Activ
•
ression
Silence Suppre
•
ort Noise Generation)
CNG (Comfo
•
TOS & Diffserv Tagging
Support TO
•
g Support
VLAN Tag
•
711 (PCM A-law or
Codec: G.7
µ-law selectable),
G.729a/b
•
6 (ADPCM), G.723*
Option: G.726
•
on
DTMF Detection
•
mber Supports
Multiple SIP Num
•
Supports
Multiple Channel Su
•
ne Detection
Modem and Fax Tone
• T.38 Fax Relay
• Polarity Reverse*
• DNS SRV*
Phone Features
• CW (Call Waiting)
• Call Waiting with Caller ID
• Call Forwarding (Unconditional/Busy/No Answer)
• Call Transferring
• Three Way Conference with local mixing
• CLIP (Calling Line Identification Presentation)
• CLIR (Calling Line Identification Restriction)
• Call Hold/Call Retrieve
• Incoming Call Policy (Call Accept/Call Forward/
Call Block)
• Second Call
• Internal Call
• Early Media
• Flash Hook Timer
• Music on Hold
• MWI (Message Waiting Indicator, RFC 3842)
• IVR (Interactive Voice Response)
• Speed Dial (Phone Book)
• DND (Do NOT Disturb)*
• MCID (Malicious Call Identification)*
• Call Block*
• Distinctive Ringing*
• Last Number Redial*
• COLP (Connected Line Identification
Presentation)*
• COLR (Connected Line Identification Restriction)*
• Conference Call with Media Server*
• Call Filtering*
• Call History*
• Automatic Call Return*
• MWI by e-Mail*
• Fixed Destination Call*
Network Functionality
• Friendly Web-based Configuration Tool
• Remote FTP/TFTP Firmware Upgrade and
Configuration Backup/Restore
• Secure TFTP and HTTP Auto-provisioning
(Default by 3DES Encryption)
• IVR for IP Address and FW Upgrade
• 2-tier Web and Management: Admin & Guest Access
Authority (by project)
NAT Traversal
• Simple Traversal of UDP over NAT (STUN, RFC3489)
• Outbound Proxy
• Manual Configured SIP and RTP (Fake address)
Management
• Embedded FTP/TFTP Server for Firmware Upgrade
and Configuration Backup and Restore
• Easy Provisioning Management of TR-104
(by project)
• Remote Management Control: Telnet, FTP, Web
• UPnP Support
Firewall Security
• ICSA Certified Firewall with Stateful Packet
Inspection
• Prevent DoS Attack
• Access Control of Service
• Content Filtering: URL Blocking Such as ActiveX,
Java, Cookies and Web
• IP & Generic Packet Filtering
• Real-time Attack Alert and Log
Environmental Specifications
• Operating Temperature: 0
°C ~ 40°C
• Storage Temperature: 0
°C ~ 60°C
• Operating Humidity: 10% ~ 85% RH
• Storage Humidity: 10% ~ 90% RH
Physical Specifications
• Dimensions: 115 (W) x 51 (D) x 165 (H) mm
• Weight: 295 g
*Firmware upgradeable for future enhancement
Specifications
Application Diagram
FXS
FXS
FXS
FXS
P-2304R-P1
P-2304R-P1
VoIP Call Serv
Server
IP Telephony
Service Provider
FXS
FXS
FXS
Broadband CPE
Bro
roadband CPE
PSTN Phone
PSTN
Network
Trunking
Gateway
IP Network
DSL Line
PSTN/ISDN Fixed Line
FXS
65-100-230401G
07/06
