YOUR APPLIANCE
OPERATING INSTRUCTION
This cooker hood is designed to extract
unpleasant odours from the kitchen, it will
not extract steam.
Cooker Hood Controls
The cooker hood functions are controlled by
four push button switches located centrally in
the control fascia.
L Turns the worktop lighting On and Off
S Mains light - illumination indicates fan
motor is running
V1 Turns the fan motor On and Off at low
speed, suitable for one pan or when
simmering.
V2 Medium fan speed, suitable for use when
cooking with a number of pots and pans.
V3 Maximum fan speed, suitable for cooking
foods with strong odours.
To Operate
Select the required fan speed and light if
required.
The appliance can be installed to recycle
(filtered) or to extract (duct) contaminated air.
The cooker hood is more effective when used in
the extraction mode.
Page 4
650 min.
507
360
898
100
360
108
244
150
min. 850
max. 1
145
740
260
300
63
90
132
433
60
L
V1 V2 V3 S
0 - 1
MID
MAX
0 - 1
