6. Set up
A Package contains the items as illustrated.
(1) Unit
(2) Harness
(3) Harness
(4) Harness
(5) Handle
(6) Cutting attachment guard
(7) Guard skirt
(8) Trimmer head
(9) Blade
(10) Cover
(11) Blade cover
(12) Hexagon socket (S16/S17) with torx driver (T-27)
(13) Hexagon socket (S16/S19) with torx driver (T-27)
(14) Bar (
4.5)
(15) Owners’ manual
1
1
1
6
7
2
3
4
5
12
14
15
11
9
8
10
BCZ4000DW
BCZ4000DW
BCZ4200CL
BCZ4200CL
BCZ4000DL
BCZ4000DL
BCZ4000DL
BCZ4000DW
BCZ4000DL
BCZ4200CL
13
