Installation Manual
XMD076A
XMD076A-3 Information is subject to the 20
Rev C , 06/22/06 restrictions on the title page
H E A D S U P T E C H N O L O G I E S
UUT NOMENCLATURE
XM Weather / Radio Wireless Receiver, RS232 Type
TYPE/MODEL/PART NO.
XMD076A-01
TSO NUMBER
N/A
MANUFACTURER’S SPECIFICATION AND/OR OTHER APPLICABLE SPECIFICATION
XMD076A-32, XMD076A-01 Qualification Test Plan
MANUFACTURER
Heads Up Technologies, Inc, 2033 Chenault Dr. #100 Carrollton, TX 75006
REVISION & CHANGE OF DO-160
E, No Change
TESTING DATES
06-08-2005 and 07-01-2005
TEST CONDITION SECTION
QUALIFICATION
CATEGORY / DESCRIPTION
LIGHTNING DIRECT EFFECTS 23.0 X (N/A)
ICING 24.0 X (N/A)
ELECTROSTATIC DISCHARGE 25.0 A (15KV Human Contact)
FIRE AND FLAMMABILITY 26.0 X (Metal External Construction)
XMC050 DO-160 Environmental Qualification Form
UUT NOMENCLATURE
XM Radio Wireless Controller
TYPE/MODEL/PART NO.
XMC050-( )
TSO NUMBER
N/A
MANUFACTURER’S SPECIFICATION AND/OR OTHER APPLICABLE SPECIFICATION
XMC050-32, XMC050 Env. Qualification Test Plan
MANUFACTURER
Heads Up Technologies, Inc, 2033 Chenault Dr. #100 Carrollton, TX 75006
REVISION & CHANGE OF DO-160
E, No Change
TESTING DATES
06-20-2005 and 07-12-2005
TEST CONDITION SECTION
QUALIFICATION
CATEGORY / DESCRIPTION
TEMPERATURE AND ALTITUDE
LOSS OF COOLING
4.0
A1 (-15°C-+55°C, De-Comp- 55KFt)
X
TEMPERATURE VARIATION 5.0 C (2°C/minute)
HUMIDITY 6.0 A (Standard Environment)
OPERATIONAL SHOCKS AND
CRASH SAFETY
7.0 X (Not qualified for this environment)
VIBRATION 8.0 X (Not qualified for this environment)
EXPLOSION 9.0 X (Not qualified for this environment)
WATERPROOFNESS 10.0 X (Not qualified for this environment)
FLUIDS SUSCEPIBILITY 11.0 X (Not qualified for this environment)
SAND AND DUST 12.0 X (Not qualified for this environment)
FUNGUS 13.0 X (Not qualified for this environment)
SALT SPRAY 14.0 X (Not qualified for this environment)
MAGNETIC EFFECT 15.0 Z (0.3m separation)
