XM Satellite Radio XMD076A - Manual (Page 23)

Installation Manual
XMD076A
XMD076A-3 Information is subject to the 19
Rev C , 06/22/06 restrictions on the title page
H E A D S U P T E C H N O L O G I E S
Appendix A Environmental Qualification Forms
XMD076A DO-160 Environmental Qualification Form
UUT NOMENCLATURE
XM Weather / Radio Wireless Receiver, RS232 Type
TYPE/MODEL/PART NO.
XMD076A-01
TSO NUMBER
N/A
MANUFACTURER’S SPECIFICATION AND/OR OTHER APPLICABLE SPECIFICATION
XMD076A-32, XMD076A-01 Qualification Test Plan
MANUFACTURER
Heads Up Technologies, Inc, 2033 Chenault Dr. #100 Carrollton, TX 75006
REVISION & CHANGE OF DO-160
E, No Change
TESTING DATES
06-08-2005 and 07-01-2005
TEST CONDITION SECTION
QUALIFICATION
CATEGORY / DESCRIPTION
TEMPERATURE AND ALTITUDE
LOSS OF COOLING
4.0
F2 (-55°C-+70°C, up to 55KFt)
X
TEMPERATURE VARIATION 5.0 B (5°C/minute)
HUMIDITY 6.0 B (Severe Environment)
OPERATIONAL SHOCKS AND
CRASH SAFETY
7.0 B (Crash: 20g random)
VIBRATION 8.0 S, Curves B and M
EXPLOSION 9.0 H (Env. II)
WATERPROOFNESS 10.0 X (Not qualified for this environment)
FLUIDS SUSCEPIBILITY 11.0 X (Not qualified for this environment)
SAND AND DUST 12.0 X (Not qualified for this environment)
FUNGUS 13.0 F (Qualified by Analysis)
SALT SPRAY 14.0 X (Not qualified for this environment)
MAGNETIC EFFECT 15.0 Z (0.3m separation)
POWER INPUT 16.0
B and Z 14V-28V
(All A/C DC systems)
VOLTAGE SPIKE 17.0 A (600V)
AUDIO FREQUENCY SUSCEPIBILTY 18.0 Z
INDUCED SIGNAL SUSCEPTIBILITY 19.0 ZC
RF SUSCEPTIBILITY 20.0 RR (Standard HIRF)
EMISSION OF RADIO FREQUENCY 21.0 M (See Note
1
)
LIGHTNING INDUCED TRANSIENT
SUSCEPTIBILITY
22.0 Z2XXX (Partially protected env.)
1
This equipment intentionally transmits low power energy in the frequency range of 2.40 to
2.48GHz and is exempt from DO-160E Section 21.4. The EUT is qualified for these transmissions
as a Class 2 Bluetooth wireless device under FCC part 15 regulations.
