Super G Wireless
Homeplug AV Router
NBG318S v2
Advanced 128-bit AES Security Protection
re, the NBG318S v2 provides secure network connection for Internet access and resource sharing. ion Security (AES) feature With the 128-bit Data n Security (AES) featu a Encryptio
nd enjoy the fast surfing experience as well as secure file transfer over the Internet. ck and Just leave the sweats to G318S v2, sit back o the NB NBG3
High Speed Wireless Access
Taking advantage o e of ZyXEL L ’ ’ L L G Technology, users can achieve data rates of up to 108 Mbps, which doubles the speed of the conventional uper G T s s Su s Wireless S ’ ’
erformance, users can handle the fast data transfer for streaming applications like video or audio pe 802.11g standa dard. With unding p h the astou
broadcastin ng effortl br rtlessly.
System Specifications
• fic Classifier MBM v2 wit M ith Automa matic Traffic
• port Powerline as W WAN or LA LAN po
• MS CHAP v1/v2 PPPoE/DHCP/PP PTP with M M
• Logging
• Web configurator
• Many to one NAT
• SIP ALG
• I Firewall DOS/DDOS SPI
• ing Port Triggerin
• DDNS
• PA2 support WPA/WPA
• /WMM 802.11e/W
• ghput indication LED throug
• ton for secure HomePlug network Encrypt butto
Hardware Specifications
• 3-port 10/100 Mbps Ethernet port with
MDI/MDIX as LAN
• 1-port 10/100 Mbps Ethernet port with
MDI/MDIX as WAN
• One Power Input: 100-240 VAC, 50 ~ 60 Hz
• LED Display on Top-Case
- Power
- Powerline Link and Activity
- Ethernet LAN Link and Activity
- Ethernet WAN Link and Activity
- Security Status
Physical Specifications
• Dimensions: 162 (W) x 118 (D) x 35 (H) mm
• Weight: 315 g
Environmental Specifications
• Operating temperature: 0ºC ~ 40ºC
• Storage temperature: -30ºC ~ 60ºC
• Operating humidity: 20% ~ 90% RH
• Storage humidity: 20% ~ 90% RH
Certification
• Safety: cUL International
• EMI: CE, FCC part 15B,ICID
• HomePlug Certification: HomePlug AV
• Wi-Fi
Specifications
Application Diagram
Super G Wireless
Homeplug AV Router
ADSL Modem
Powerline
Ethernet
Outlet
Outlet
Outlet
Outlet Outlet
PLA-400 v2
Powerline
Ethernet Adapter
Powerline as Internet Sharing
Powerline as Broadband Extension
ADSL Modem
F o r m o r e p r o d u c t i n f o r m a t i o n , v i s i t u s o n t h e w e b a t w w w . Z y X E L . c o m
65-100-031802B 01/08
Copyright © 2008 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of ZyXEL Communications Corp. All other brands,
product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
