4
CONFIGURATION MENU
Non- Displayed Press or
Program- Program- Press (Factory to select from
mable mable Button Default) listed options Comments
1 1 MS 2 HP 1, HP 2, SS 1 Selects Multi-Stage (MS 2, No Heat Pump), Heat Pump 1
(HP 1, 1 compressor), Heat Pump 2 (HP 2, 2 compressor
or 2 speed compressor), or Single Stage.
2 2 (GAS) ELE GAS setting: furnace controls blower.
ELE setting: thermostat controls blower.
3 3 Days (7) 5, 0 Selects programming option.
4 * NA PS (4) 2 Selects programming steps per day.
5 4 Cool Off Cool Off Heat (Emer), Selects system switch configuration for Heat and Cool with
Heat Auto Off Heat, Cool Off Auto changeover, Heat & Cool, Heat Only or Cool Only.
6 * NA E (On) OFF Selects Energy Management Recovery on or off.
7 5 Cr Heat (FA) SL Selects Heat cycle rate Fast (FA) or Slow (SL).
8 6 Cr Cool (FA) SL Selects Cool cycle rate Fast (FA) or Slow (SL).
9 7 Cr Emer (FA) SL If HP 1 or HP 2 is selected for item #1, selects Emer cycle
rate.
10 8 CL (OFF) On Selects Compressor lockout ON or OFF.
11 9 dL (On) OFF Selects display light on or off.
12 10 0 1, 2, 3, 4 HI Selects temperature display adjustment 1, 2, 3 or 4 degrees
(Room temp) 1, 2, 3, 4 LO high or low.
13 11 °F °C Selects Fahrenheit or Celsius temperature display.
14 12 b (On) OFF Selects beeper on or off.
15 13 Heat (99) 62-99 Selects highest Heat setpoint temperature.
Can select 62° to 99°F.
16 14 Cool (45) 45-82 Selects lowest Cool setpoint temperature.
Can select 45° to 82°F.
17 15 Keypad L, P Selects keypad lockout full or partial to be set.
lockout (L) Temperature Limit Activates temperature limit ranges.
18 16 Keypad On Selects keypad lockout on or off.
lockout (OFF)
000 000 to 999 Selects keypad lockout combination number if lockout is on.
000 is not a valid selection.
19 17 FA Heat (On) OFF If HP or MS selected in item 1, selects Heat Fast second
stage On or Off.
20 18 FA Cool (On) OFF If HP or MS selected in item 1, selects Cool Fast second
stage On or Off.
21 19 000 Change On Select change filter alert time period.
Filter (OFF)
200 hours 25 to 1975 hours When set ON, selects time in 25 hour increments.
22 20 Change On Selects change humidifier pad alert time period
Humidifier
(OFF)
100 hours 25 to 1975 hours When set ON, selects time in 25 hour increments.
INSTALLER/CONFIGURATION MENU
To enter the menu: Press the Menu button. Press and hold for 5 seconds the Installer Config button. This displays menu
item #1 in the table below. Press to advance to the next menu item or to return to a previous menu item. Press or
to change a menu item.
1) This control can be configured for:
MS2 – Multi-Stage System (no heat pump)
HP1 – Heat Pump with one stage of compressor
HP2 – Heat Pump with two stage compressor or two
compressor system, Gas or Electric backup
SS1 – Single Stage System
2) GAS or Electric (ELE) fan operation. If the heating system
requires the thermostat to energize the fan, select ELE.
Select GAS if the heating system energizes the fan on a
call for heat.
Note: Resetting the thermostat switches
the option to ELE.
3) This control can be configured for 7 independent day or
5/1/1 day programming or non-programmable mode. The
display indicates "
7 Days" as default. The programs per
week can be toggled to " 5 Days" or "0 Days" by pressing
the or keys. A selection of 0 Days for non-program-
mable will eliminate the need for EMR, and that step
in the menu will be skipped.
4) Programmable Periods – This control can be configured
for 4 or 2 programmable periods per day. The display
indicates "
4 PS" in the display as default. The program-
mable periods can be toggled by pressing the or
keys.
Menu
Reference
Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
* Not Applicable
