M10 Nylon Locknut (103)

M10 Lock Washer (75)

31mm Spacer (30)

1/2" Lock Washer (12)

M4 x 70mm Screw (114)

M10 x 25mm Button Screw (88)

M10 x 64mm Button Bolt (80)

M10 x 75mm Button Bolt (84)

M10 x 92mm Button Bolt (83)

M10 x 125mm Button Bolt (89)

M10 x 152mm Bolt (86)

3/8" x 38mm Tension Screw (117)

M12 x 58mm Button Bolt (87)

M12 x 62mm Button Bolt (81)

M12 Nylon Locknut (13)

38mm Spacer (90)

M10 x 58mm Button Screw (11)

M10 x 85mm Button Bolt (92)

M10 Washer (106)

1/2" x 25mm Screw (85)

M10 Thick Washer (54)

PART IDENTIFICATION CHART—Model No. WESY78734

REMOVE THIS PART IDENTIFICATION CHART AND PART LIST/
EXPLODED DRAWING. SAVE THIS PART IDENTIFICATION CHART
AND PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE.
