RECOVERY TANK ASSEMBLY
ADMIRAL 86038230 03/16/07
5-14
REF PART
NO. PRV
NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1A
86002400
20064
1
CLAMP, 2.0" WORM GEAR X .312
1000083447
1B
86002350
20002
1
CLAMP, 2.0” NYLON RATCHET
2
86233140
20041
1
CLAMP, 2.0" WORM GEAR
3
86008400
78499
1
TETJER, DRAIN PLUG
4
86003110
27816
2
COVER, REC. TANK
5
86235280
28060
1
DOME, CLP FAMILY
6
86003630
34351
1
FLOAT SHUT-OFF
7
86003910
35230
1
GASKET, DOME
8
86003930
35232
2
GASKET, PORT COVER
9
86004200
39353
1
HOSE, 1.5 X 12.0 DRAIN
10A 86004510 41391
1 HOSE,
INSERT
1000083447
10B 86004450 40019
1 HOSEBARB,
1.5 DOUBLE MCHD
11A 86004500 41390
1 HOSE,
CAP
1000083447
11B 86006240 66227
1 PLUG
DRAIN
HOSE
12
86006600
70114
6
SCR, #10 X 3/4 PPHST TYPE B
13
86032270
75260
1
TANK, ADM RECOVERY
14A
86001370
140408
1
BRKT, HOSE HOOK
1000083447
14B
86001190
140133
1
BRKT, RECOVERY HOSE MTG
15
86002870
27417
1
CORD, 99807 1/8 X 12"
16 86242230 500009 1 LABEL,
WARNING
17
86245930
50994
1
LABEL, ADMIRAL MAIN
18 86003330 28061 1 DOME
ASM
