Using single-ended amplifiers
If	your	power	amplifier	does	not	have	balanced	inputs,	the	adapter	used
to	convert	from	balanced	to	single-ended	must	“float”	Pin	3	(the	inverted
signal).	This	can	easily	be	checked	with	an	ohmmeter:	the	impedance	be-
tween	Pin	3	and	either	the	center	pin	or	the	shield	skirt	on	the	RCA	should
be infinite. Tying the output of Pin 3 to ground (as some adapters do) will
compromise	the	performance	of	the	SC-1.	Should	you	need	them,	prop-
erly	wired	adapters	are	available	from	Wisdom	Audio	for	an	additional
charge,	or	they	can	be	purchased	online	at
http://www.markertek.com/Connectors-Adapters/Audio-Adapters/XLR-to-
RCA-Adapters/Switchcraft-Corporation/322X.xhtml.
5
USB Port
This USB port is used by your installer to connect a Windows-compatible
PC	for	setup	and	calibration.	It	provides	two-way	communication	between
the	SC-1	and	the	computer	that	is	used	for	adjusting	the	many	parameters
of	the	system	controller.
6
RS232 Interface
The RS232 interface allows an external control system such as AMX, Con-
trol4,	Crestron,	or	Savant	to	control	the	SC-1.	All	basic	operational	modes
are	supported	(operate,	standby,	selecting	setup	memories).
When the SC-1 is first powered up, it will identify itself to the control
system via the RS-232 port, sending either
Wisdom Audio SC-1
or
Wisdom Audio SC-1
Ready...
ERROR
…depending on whether there is at least one setup memory that has been
calibrated	and	is	available	for	use.	(For	proper	operation,	at	least	one	setup
memory	must	be	saved	into	the	SC-1’s	non-volatile	memory.)
The RS232 port is wired as a DCE, and connects via a straight cable to a
DTE, or via a null modem/crossover cable to another DCE (uncommon).
•
Pin 2 is the TRANSMIT for data FROM the SC-1 TO the control
system, and carries RS232 signal name RxD
•
Pin	3	is	the	RECEIVE	for	data	FROM	the	control	system	TO	the
SC-1,	and	carries	RS232	signal	name	TxD
•
Pin 5 is the GROUND/COMMON for the pin 2 and pin 3 sig-
nals
The other pins are not connected, the shell is grounded at the same point
as	pin	5.		Signal	names	RxD	and	TxD	are	named	from	the	point	of	view	of
the	DTE	and	that’s	why	the	names	appear	to	be	backward	but	are	not	per
the	standard.
Off	the	shelf	USB->RS232	adapters	plug	right	in	to	the	port	and	work	as
expected	without	special	configuration.
The commands available to your control system programmer are as fol-
lows:
