SUGGESTED SPARE PARTS
ADMIRAL 86038230 5-15
PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
86001140 12514 BRUSH, 15L X 3.38OD WAS 12031
86001100 11045 BELT, 180J6 MICRO-V
86000900 09019 BEARING, 1.125ODX.500IDX.375
86004570 44067 JET BODY, MINI PROMAX BODY
86241680 44073 JET, MINI PROMAX 8003 WAS 44072
86026390 65201 PUMP ASM, CLP/ADM
86026940 84160
VALVE ASM, SOLENOID CLP
FAMILY
86003780 35171 GASKET, ACCESSORY PORT
86001980 14700 BREAKER, 15A 250VAC 50VDC
86230210 14832 BREAKER, 6A VDE CIRCUIT
86007140 72130
SWITCH, SPST 2-POSITION
ROCKER
86007200 72162
SWITCH, DPDT3-POSITION
ROCKER
86026880 53789 VAC MOTOR ASM, CLP FAMILY
86007970 73864 STRAINER, 3/8 IN. NPT 60 MESH
86003330 28061 DOME ASM, CLP FAMILY
86003630 34351 FLOAT SHUT-OFF
86006240 66227 PLUG, DRAIN HOSE
86135340 14258
BRUSH SET, 120V 5.7 VAC,
AMATEK
86135320 140687 BRUSH SET, 120V VAC, WINDSOR
