Rolling grilles – Wayne-Dalton 600 User Manual
Page 5
NOTE: Dimensions are for general reference
only and not for construction purposes.
Aluminum Grilles
WIDTH
HEIGHT
BRACKET
SIZE
X
Y
W
R
L
30'
6'0"
14"
14"
14-1/2"
17"
SEE SKETCH SEE SKETCH
30'
7'1"
15"
15"
15-1/2"
18"
SEE SKETCH SEE SKETCH
30'
7'11"
16"
16"
16-1/2"
19"
SEE SKETCH SEE SKETCH
30'
10'4"
17"
17"
17-1/2"
20"
SEE SKETCH SEE SKETCH
30'
12'0"
18"
18"
18-1/2"
21"
SEE SKETCH SEE SKETCH
30'
14'6"
19"
19"
19-1/2"
22"
SEE SKETCH SEE SKETCH
25'
18'0"
20"
20"
20-1/2"
23"
SEE SKETCH SEE SKETCH
30'
17'2"
20"
20"
20-1/2"
23"
SEE SKETCH SEE SKETCH
25'
20'0"
21"
21"
21-1/2"
24"
SEE SKETCH SEE SKETCH
30'
18'0"
21"
21"
21-1/2"
24"
SEE SKETCH SEE SKETCH
30'
20'0"
23"
23"
23-1/2"
26"
SEE SKETCH SEE SKETCH
Steel Grilles and Stainless Steel Grilles
WIDTH
HEIGHT
BRACKET
SIZE
X
Y
W
R
L
30'
7'0"
16"
16"
16-1/2"
19"
SEE SKETCH SEE SKETCH
30'
10'0"
17"
17"
17-1/2"
20"
SEE SKETCH SEE SKETCH
30'
7'11"
16"
16"
16-1/2"
19"
SEE SKETCH SEE SKETCH
30'
12'0"
18"
18"
18-1/2"
21"
SEE SKETCH SEE SKETCH
26'
15'0"
19"
19"
19-1/2"
22"
SEE SKETCH SEE SKETCH
30'
14'0"
19"
19"
19-1/2"
22"
SEE SKETCH SEE SKETCH
28'
18'0"
20"
20"
20-1/2"
23"
SEE SKETCH SEE SKETCH
30'
17'0"
20"
20"
20-1/2"
23"
SEE SKETCH SEE SKETCH
16'
20'0"
21"
21"
21-1/2"
24"
SEE SKETCH SEE SKETCH
25' TO 30'
18'0"
21"
21"
21-1/2"
24"
SEE SKETCH SEE SKETCH
30'
20'0"
23"
23"
23-1/2"
26"
SEE SKETCH SEE SKETCH
ROLLING GRILLES
6 0 0
S E R I E S
