g) Lift and twist the burner assembly slightly, to separate
the crossover tube from the burners. Figure 14.
Remove the burners from the cooking box.
29
Crossover tube
Figure 14
d) Unlatch the Spider Stopper Guards and remove.
Figure 11.
Figure 11
View from behind
cooking box
Wing nuts
Figure 12
Guide screw
Figure 13
h) To reinstall burners, reverse steps c) through g).
ƽ
CAUTION: The burner openings must be
positioned properly over the valve orifices. Figure 15a.
Check proper assembly before fastening manifold in place.
Figure 15b.
Figure 15
Valve
Burner
(a)
(b)
e) Remove the manifold bracket and unscrew the two
wing nuts that hold the manifold to the cooking box.
Pull the manifold and valve assembly out of the
burners and carefully set it down. Figure 12.
f) Slide the burner assembly out from under the guide
screw and washer in the corners of the cooking box.
Figure 13.
