Insert casters, Install side burner locks – weber GENESIS 3300 User Manual
Page 12

12
Step 7
Install side burner locks
Note: The locks are taped to the inside of the side
burner lid.
You will need: frame assembly, two side burner locks and
a 7/16 inch wrench.
Turn frame assembly right side up.
Loosen the right rear 1/4 x 20 bolt. Install the side burner
lock. The “U” shape cut out of the lock slips down over the
bolt. Tighten with a wrench. Figure 6 (a).
Loosen the right front 1/4 x 20 bolt. The side burner lock
fits between the front panel and the frame. The “U” shape
cut out slips up over the bolt. Tighten with a wrench.
Figure 6 (b).
Figure 6
Step 6
Insert casters
You will need: frame assembly and two casters.
Push the casters firmly into the inserts in the ends of the
caster legs. Figure 5.
Figure 5
(a)
(b)
