6
4. Attach the Row Plate (28) to the Upright (2) with
four M10 x 75mm Button Bolts (84) and four M10
Nylon Locknuts (103).
4
2
103
103
84
84
3. Insert the Upper Wire Harness (71) through the
hole in the Upright Cover (3). Pull the lower end
of the Upper Wire Harness out of the hole in the
back of the Upright (2).
Attach the Upright Cover (3) and Upright (2) to
the Base Plate (1) with an M10 x 25mm Button
Screw (88), an M10 Washer (106), an M10 x
92mm Button Bolt (83), and an M10 Nylon
Locknut (103).
3
28
88
2
3
71
71
1
83
106
103
