Control panel, Control panel parts – Whirlpool GMC305PRS02 User Manual
Page 3
CONTROL PANEL PARTS
3
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION
1 W10105800 Assembly, Control
2
8303948 Assembly, Switch
3 W10153086 Backer, Control
4
8301848 Board, Motorized
Latch
5
8302848 Control Panel
6
4451592 Filter
7
4451632 Bracket, Filter
8
4449745 Screw
9
4449809 Screw
10 W10144998 Trim, Cooktop
