OVEN PARTS
2
For Models:GMC305PRS02
(Stainless)
W10163659
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
Literature Parts
Installation
Instructions
8303655 English
8303780 French
Use & Care Guide
(Microwave)
8304078 English
8304082 French
Use & Care Guide
(Oven)
8304077 English
8304081 French
8304173 Tech Sheet (Oven)
Safer Cooking Tips
3191638 English
9759133 French
2
Trim, Side
W10145006 Right
W10145007 Left
3
Hinge, Receiver
4455606 Right
4455605 Left
4 W10105790 Bumper, Door
5
4448444 Grommet, Mounting
Rail
6
4452490 Spacer, Foam
7
8303099 Top, Chassis
8
4449809 Screw
9
4452158 Tube, Vent
10 W10067870 Lens, Light
11 W10009930 Assembly, Oven
Light
12
4452166 Bulb, Light
13
8300791 Bracket, Combo
14 W10130368 Frame, Front
15
4455382 Gasket, Door
16
3400832 Screw
17
3196176 Screw
18
4452152 Bracket, Mounting
19
4451478 Support, Insulation
21
Rail, Side
8303117 Right
8303118 Left
22
4449040 Screw
23
4449743 Screw
24
4449154 Screw
25
4455641 Side, Chassis
26
4452234 Back, Chassis
27
Liner, Oven
(Not Serviceable)
29
4455636 Sensor
30
4449845 Bracket, Support
31
4450038 Screw
33
9760677 Deflector, Vent
34
8302592 Vent, Center
35
4449906 Ext−Filler
37
9759243 Thermostat (TOD)
43
9759713 Base, Chassis
49
4448933 Retainer, Gasket
50
4451747 Cover, Back
51 W10145001 Trim, Vent
Bottom
52
8303502 Vent, Control
53
4451756 Chassis, Back
FOLLOWING PARTS
NOT ILLUSTRATED
INSULATION
4449316 Insulation, Wrap
4450365 Insulation, Back
