Cabinet parts – Whirlpool GCGM2991TQ0 User Manual
Page 5
CABINET PARTS
5
For Model: GCGM2991TQ0
(White)
W10119636
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1
3396805 Panel, Rear
2
3394975 Plug, Front Panel
3
697776 Screw, Ground
10−32 x 5/8
4
3403630 Plug, Strike
5
388326 Screw,
8−18 x 1−1/4
6
8541400 Bracket, Cabinet
7
343641 Screw, 10−16 x 1/2
8
697773 Screw, 6−20 x 7/8
9
693995 Screw, Hex Head
8−18 x 3/8
10
3980175 Clamp−Elbow
14
3404413 Plug, Hinge Hole
15
3396795 Cover, Block
16
238088 Hinge, Top (2)
17
3406109 Door Switch
Assembly
18
3401401 Cord, Power
19
341029 Clamp, Pipe
(Rear)
21
98234 Clip, Ground (2)
22
3406129 Seal & Bearing
Assembly
23
3401771 Burner Assembly
(60 Hz.)
(Refer to Pages
8 & 9 For Further
Breakdown)
24
3403447 Front Panel
Assembly
25
3392100 Foot, Plastic
279810 Foot − Optional
(Extended Length
Package Of 2)
(Not Included)
28
8530603 Cabinet
(Includes
Illus. 6)
32
686590 Ignitor
33
690363 Lock, Front Top
34
685203 Clip, Felt Pad (2)
35
3393909 Screw & Washer
36
3394083 Clip, Front Panel
37
3389441 Catch, Door
Assembly
38
8066206 Motor Assembly,
60 Hz.
39
348780 Base, Motor
40
8066065 Belt, Drive
41
3400500 Bolt,
5/16−18 x 3/4
42
8281908 Valve, Gas
(Complete)
60 Hz.
44
691366 Idler & Pulley
Assembly
46
660658 Clip, Motor
47
3404162 Clamp, Motor
48
8066184 Pulley, 60 Hz.
52
3405246 Seal, Door
54
3403431 Strike, Door
58
3405514 Hinge, Door
60
342055 Screw, 8−18 x 1/2
61
3402341 Door, Rear
63
3402335 Door, Front
64
3405184 Handle, Door
